002921066
IZ16/2F/12 Insulated busbar
- ETI Code:
- 002921066
- To use with:
- ETIMAT 6, ETITEC, SV, VLD01, ETIMAT P10
- Catalogue Group:
- IZ Section rails
- Type description:
- Fork Type
- Number of poles:
- 2
- Function:
- Section rails
- Busbar type:
- FORK
- Rated current:
- 100 A
- Rated cross section:
- 16 mm²
- Lenght in modules:
- 1x12
- No. Of Phases:
- 2
- Rated AC voltage:
- 500 V
- Rated DC voltage:
- 500 V
- Type accessories:
- Section rails
5 Documents
16 Logistics
Product
- EAN code for a single product
- 3838400042767
- Net weight of the product
- 0.27 kg
- Net width
- 215 mm
- Net height
- 29.4 mm
- Net depth
- 10.2 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 10 pcs
- EAN code for a basic packaging
- 5907563671218
- Basic packaging weight
- 1.261 kg
- Basic packaging volume
- 0.166 dm³
Transport Packaging
- Transport packaging quantity
- 120 pcs
- EAN code for a transport packaging
- 5907563671225
- Transport packaging weight
- 15.425 kg
- Transport packaging volume
- 20 dm³
- Pallet quantity
- 6,000 pcs
- Customs tariff
- 85389099
9 ETIM
- Cross section
- 16 mm²
- Suitable for devices with N-conductor
- Yes
- Number of phases
- 2
- Rated permanent current Iu
- 100 A
- Module width
- 17.8 mm
- Length
- 210 mm
- Max. rated operation voltage Ue
- 500 V
- Insulated
- Yes
- Type of electric connection
- Fork
ETIM Classification – Version 9.0
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
23 Tags
002921066Insulated busbarIZ16/2F/12ETIBOXAccessoriesSection railsSection railsFork typeFork typeInternationalEnclosures, distribution boards, equipment ETIBOXSection railsBusbar type: FORKFunction: Section railsType accessories: Section railsNumber of poles: 2Lenght in modules: 1x12Rated cross section: 16 mm²-16 mm²Rated AC voltage: 500 V/500 VRated DC voltage: 500 V/500 VRated current: 100 A/100 ANo. Of Phases: 2Insulated busbar TOWAR Function: Section rails Busbar type: FORK
