VL D01 6A 3p+N Fuse switch disconnector
- ETI Code:
- 002261021
- To use with:
- D0 fuse-links
- Catalogue Group:
- LV-fuse disconnector
- Standards:
- IEC60269-1, IEC60269-3, IEC60947-1, IEC60947-3
- Application:
- Residential and industrial installation
- Type description:
- VL D01
- Type of Installation:
- DIN rail
- Utilization category:
- AC-22A
- Size:
- D01
- Product group:
- LV-fuse disconnector
- Rated AC voltage:
- 400 V
- Rated DC voltage:
- 400 V
- Rated current:
- 6 A
- Number of poles:
- 3+N
7 Documents
22 Logistics
Product
- EAN code for a single product
- 3838400030429
- Net weight of the product
- 0.342 kg
- Net width
- 70.4 mm
- Net height
- 88 mm
- Net depth
- 74.67 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 3 pcs
- EAN code for a basic packaging
- 3838895329565
- Basic packaging weight
- 1.082 kg
- Basic Packaging Dimensions Height
- 0.077 m
- Basic Packaging Dimensions Width
- 0.09 m
- Basic Packaging Dimensions Depth
- 0.221 m
- Basic packaging volume
- 0.002 m³
Transport Packaging
- Transport packaging quantity
- 27 pcs
- EAN code for a transport packaging
- 3838895329572
- Transport packaging weight
- 10.091 kg
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- Transport packaging volume
- 0.017 m³
- Pallet quantity
- 1,404 pcs
- Customs tariff
- 85389099
4 ETIM
- Construction size
- D01
- Number of poles
- 4
- Rated voltage
- 400 V
- Rated current
- 6 A
