STV D02 1p 63A/400V komplet Switch disconnector fuse
- ETI Code:
- 002271101
- Ambient temperature:
- -5/40 °C
- Standards:
- IEC60269-1, IEC60269-3, IEC60947-1, IEC60947-3
- Catalogue Group:
- LV-fuse disconnector SET (including proper fuse, gauge piece and adaptor)
- Breaking capacity AC:
- 50 kA
- To use with:
- D0 fuse-links
- Application:
- Residential and industrial installation
- Type description:
- STV D02 SET
- Type of Installation:
- DIN rail
- Utilization category:
- AC-22A
- Size:
- D02
- Product group:
- LV-fuse disconnector
- Rated AC voltage:
- 230/400 V
- Rated DC voltage:
- 110 V
- Rated current:
- 63 A
- Number of poles:
- 1
22 Logistics
Product
- Net depth
- 69.22 mm
- Net weight of the product
- 0.144 kg
- Net width
- 26.8 mm
- Net height
- 89.2 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838400030658
Basic Packaging
- EAN code for a basic packaging
- 3838895580959
- Basic packaging weight
- 1.794 kg
- Basic Packaging Dimensions Depth
- 0.327 m
- Basic Packaging Dimensions Height
- 0.083 m
- Basic packaging volume
- 0.003 m³
- Basic Packaging Dimensions Width
- 0.097 m
- Basic packaging quantity
- 12 pcs
Transport Packaging
- Transport packaging weight
- 14.901 kg
- Transport packaging volume
- 0.029 m³
- Transport packaging quantity
- 96 pcs
- Customs tariff
- 85389099
- Transport Packaging Dimensions Height
- 0.215 m
- Transport Packaging Dimensions Width
- 0.368 m
- Transport Packaging Dimensions Depth
- 0.368 m
- EAN code for a transport packaging
- 3838895580966
- Pallet quantity
- 2,304 pcs
4 ETIM
- Construction size
- D02
- Number of poles
- 1
- Rated voltage
- 400 V
- Rated current
- 63 A
