002176205
KZS-1MS 1p+N A B16/0.03 RCBO
- ETI Code:
- 002176205
- Rated AC voltage:
- 230 V
- Application:
- EN/IEC 61009
- Rated residual operating current IDn:
- 0.03 A
- Rated current:
- 16 A
- Residual current type:
- A
- Rated residual current:
- 0.03 A
- Tripping characteristic:
- B
- Number of poles:
- 1+N
- Short circuit capacity:
- 6 kA
- Tripping time:
- Instantaneous
- Rated Frequency:
- 50/60 Hz
- Rated cross section:
- 110 mm²
- Standards:
- EN/IEC 61009
1 Documents
11 Logistics
Product
- Net weight of the product
- 0.115 kg
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838400143372
- Transport packaging weight
- 0.133 kg
- Transport Packaging Dimensions Height
- 80 mm
- Transport Packaging Dimensions Width
- 20.5 mm
- Transport Packaging Dimensions Depth
- 91.5 mm
- Transport packaging volume
- 0.15 dm³
- Pallet quantity
- 5,200 pcs
- Customs tariff
- 85362010
16 ETIM
- Leakage current type
- A
- Voltage type
- AC
- Release characteristic
- B
- Rated fault current
- 0.03 A
- Number of poles (total)
- 2
- Disconnection characteristic
- Undelayed
- Frequency
- 50/60 Hz
- Rated short-circuit breaking capacity according to EN 61009
- 6 kA
- Concurrently switching neutral conductor
- Yes
- Number of protected poles
- 1
- Rated voltage
- 230 V
- Rated current
- 16 A
- Connectable conductor cross section solid-core(Min)
- 0.75 mm²
- Connectable conductor cross section multi-wired(Min)
- 0.75 mm²
- Connectable conductor cross section solid-core(Max)
- 10 mm²
- Connectable conductor cross section multi-wired(Max)
- 6 mm²
ETIM Classification – Version 9.0
