004671523
EB2R-M 125/4L 100A 4P Molded Case Circuit Breaker
- ETI Code:
- 004671523
- Application:
- 60947
- Function:
- MCCB + RCD
- Rated current:
- 100 A
- Number of poles:
- 4
- Connection type:
- front connection
- Standards:
- 60947
- Rated impulse withstand voltage Uimp:
- 8 kV
- Rated short-circuit breaking capacity at 415V Icu/Ics:
- 25/19 kA
- Rated operational voltage (AC):
- 525 V
- Rated Insulation Voltage:
- 800 V
- Thermal Adjustment:
- 0,63-1
- Magnetic adjustment:
- fixed
- Adjustable or fixed:
- adjustable
- Frame Size:
- 125A
- Short circuit capacity:
- 25/19 kA
5 Documents
11 Logistics
Product
- Net depth
- 92 mm
- Net weight of the product
- 1.5 kg
- Net width
- 120 mm
- Net height
- 155 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging weight
- 1.4 kg
- Transport packaging volume
- 1.2 dm³
- Transport packaging quantity
- 1 pcs
- Customs tariff
- 85362090
- EAN code for a transport packaging
- 3838895502609
- Pallet quantity
- 571 pcs
