002440568
Obsolete
*ETITEC ZP T12 300/12,5 3+0 RC Surge arrester
- ETI Code:
- 002440568
- Function:
- SPD
- Surge arrester type:
- T1, T2
- Uc Continous Operating Voltage AC:
- 300 V
- Iimp(10/350) Impulse Current:
- 12.5 kA
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
- Current type:
- AC
- Rated AC voltage:
- 230 V
- Up - Voltage Protection Level:
- 1.5 kV
- Remote signalisation:
- Yes
- Leakage Current:
- No
- Network system:
- TN-C
- Number of modules:
- 3
- Installation:
- Home and residental building protection
- Built-in depth:
- 88 mm
- IP rating:
- IP20
- Applied Technology:
- MOV, GDT
- Catalogue Group:
- ETITEC ZP
3 Documents
12 Logistics
Product
- Net weight of the product
- 0.87 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895847632
- Basic packaging weight
- 0.87 kg
- Basic packaging volume
- 1.914 dm³
Transport Packaging
- Transport packaging quantity
- 18 pcs
- EAN code for a transport packaging
- 3838895847649
- Transport packaging weight
- 15.66 kg
- Transport packaging volume
- 41 dm³
- Pallet quantity
- 468 pcs
- Customs tariff
- 85363090
12 ETIM
- System configuration TN-C
- Yes
- Remote signalling
- Yes
- Nominal voltage AC
- 230 V
- Test class
- Type 1 + 2
- Degree of protection (IP)
- IP20
- Mounting method
- Busbar
- Construction size
- Other
- Lightning impulse current (10/350 µs)
- 12.5 kA
- Voltage protection level
- 1.5 kV
- Number of poles
- 3
- Signalling at the device
- Optical
- Max. continuous voltage AC
- 300 V
ETIM Classification – Version 9.0
