002440594
ETITEC ZPS T12 300/12,5 3+0 RC Surge arrester
- ETI Code:
- 002440594
- Function:
- Ogranicznik przepięć
- Surge arrester type:
- T1, T2, T3
- Uc Continous Operating Voltage AC:
- 300 V
- Iimp(10/350) Impulse Current:
- 12.5 kA
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
- Current type:
- AC
- Remote signalisation:
- Yes
- Leakage Current:
- No
- Network system:
- TNC
- Installation:
- Home and residental building protection
- Catalogue Group:
- ETITEC ZPS T12
3 Documents
18 Logistics
Product
- Net weight of the product
- 0.712 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895896517
- Basic packaging weight
- 0.783 kg
- Basic Packaging Dimensions Height
- 52 mm
- Basic Packaging Dimensions Width
- 105 mm
- Basic Packaging Dimensions Depth
- 245 mm
- Basic packaging volume
- 1.338 dm³
Transport Packaging
- Transport packaging quantity
- 18 pcs
- EAN code for a transport packaging
- 3838895896524
- Transport packaging weight
- 15.507 kg
- Transport Packaging Dimensions Height
- 380 mm
- Transport Packaging Dimensions Width
- 370 mm
- Transport Packaging Dimensions Depth
- 260 mm
- Transport packaging volume
- 36.556 dm³
- Pallet quantity
- 324 pcs
- Customs tariff
- 85363090
