002440420
ETITEC D T3 440/3 1+0 RC Surge arrester
- ETI Code:
- 002440420
- Function:
- SPD
- Surge arrester type:
- T3
- Uc Continous Operating Voltage AC:
- 440 V
- Nominal Discharge Current (8/20 μs) In:
- 3 kA
- Current type:
- AC
- Rated AC voltage:
- 400 V
- Up - Voltage Protection Level:
- 16 kV
- Remote signalisation:
- Yes
- Leakage Current:
- Yes
- Network system:
- IT
- Number of modules:
- 1
- Installation:
- Home and residental building protection
- Built-in depth:
- 66 mm
- IP rating:
- IP20
- Applied Technology:
- MOV
- Catalogue Group:
- ETITEC D
5 Documents
21 Logistics
Product
- Net weight of the product
- 0.137 kg
- Net width
- 17.8 mm
- Net height
- 102.9 mm
- Net depth
- 72.59 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895773207
- Basic packaging weight
- 0.167 kg
- Basic Packaging Dimensions Height
- 76 mm
- Basic Packaging Dimensions Width
- 24 mm
- Basic Packaging Dimensions Depth
- 109 mm
- Basic packaging volume
- 0.199 dm³
Transport Packaging
- Transport packaging quantity
- 12 pcs
- EAN code for a transport packaging
- 3838895773214
- Transport packaging weight
- 2.085 kg
- Transport Packaging Dimensions Height
- 79 mm
- Transport Packaging Dimensions Width
- 298 mm
- Transport Packaging Dimensions Depth
- 112 mm
- Transport packaging volume
- 2.637 dm³
- Pallet quantity
- 4,020 pcs
- Customs tariff
- 85363090
13 ETIM
- Max. conductor cross section flexible (fine-strand)
- 25 mm²
- Nominal voltage AC
- 400 V
- Max. conductor cross section solid (solid, stranded)
- 35 mm²
- Degree of protection (IP)
- IP20
- Mounting method
- DIN rail (top hat rail) 35 mm
- Category type 3
- Yes
- Voltage protection level
- 1.6 kV
- Number of poles
- 1
- Signalling at the device
- Optical
- Max. continuous voltage AC
- 440 V
- With remote signalling contact
- Yes
- Total discharge current (8/20) (L+N-PE)
- 5 kA
- Nominal discharge surge current (8/20) (L-N)
- 3 kA
ETIM Classification – Version 9.0
