002440422
MOD.ETITEC D T3 440/3 Surge arrester
- ETI Code:
- 002440422
- Rated AC voltage:
- 400 V
- Network system:
- IT
- Catalogue Group:
- ETITEC D
- Installation:
- Home and residental building protection
- IP rating:
- IP20
- Leakage Current:
- Yes
- Applied Technology:
- MOV
- Surge arrester type:
- T3
- Uc Continous Operating Voltage AC:
- 440 V
- Function:
- SPD Module
- To use with:
- ETITEC D T3
- Current type:
- AC
- Nominal Discharge Current (8/20 μs) In:
- 3 kA
5 Documents
15 Logistics
Product
- EAN code for a single product
- 3838895773245
- Net weight of the product
- 0.06 kg
- Net width
- 17.8 mm
- Net height
- 46.6 mm
- Net depth
- 52 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 12 pcs
- EAN code for a transport packaging
- 3838895773252
- Transport packaging weight
- 0.752 kg
- Transport Packaging Dimensions Height
- 77 mm
- Transport Packaging Dimensions Width
- 113 mm
- Transport Packaging Dimensions Depth
- 99 mm
- Transport packaging volume
- 0.861 dm³
- Pallet quantity
- 11,160 pcs
- Customs tariff
- 85363090
9 ETIM
- Nominal voltage AC
- 400 V
- Degree of protection (IP)
- IP20
- Mounting method
- On basic element
- Category type 3
- Yes
- Voltage protection level
- 1.6 kV
- Signalling at the device
- Optical
- Max. continuous voltage AC
- 440 V
- Total discharge current (8/20) (L+N-PE)
- 5 kA
- Nominal discharge surge current (8/20) (L-N)
- 3 kA
ETIM Classification – Version 9.0
