002445222
Obsolete
* MOD.ETITEC C-PV 550/20 Surge arrester
- ETI Code:
- 002445222
- Surge arrester type:
- T2
- Catalogue Group:
- ETITEC C PV
- Installation:
- PV protection
- Applied Technology:
- MOV
- Leakage Current:
- Yes
- IP rating:
- IP20
- Uc Continous Operating Voltage DC:
- 550 V
- Function:
- SPD Module
- To use with:
- ETITEC C PV
- Current type:
- DC
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
2 Documents
8 Logistics
Product
- Net weight of the product
- 0.052 kg
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging weight
- 0.62 kg
- Transport packaging volume
- 1.6 dm³
- Transport packaging quantity
- 12 pcs
- Customs tariff
- 85363090
- EAN code for a transport packaging
- 3838895615941
- Pallet quantity
- 13,500 pcs
9 ETIM
- Max. discharge surge current (8/20)
- 40 kA
- Max. continuous voltage DC
- 550 V
- Degree of protection (IP)
- IP20
- Mounting method
- On basic element
- Construction size
- 1 modular spacing
- Signalling at the device
- Optical
- Category type 2
- Yes
- Nominal discharge surge current (8/20)
- 20 kA
- System configuration DC
- Yes
ETIM Classification – Version 9.0
