PV surge arrestors, also known as surge protective devices (SPDs), are critical for safeguarding photovoltaic (PV) systems from overvoltage events caused by lightning strikes or other electrical disturbances. These devices are designed to limit the voltage and divert the surge current away from sensitive PV equipment, such as solar panels and inverters, thus preventing damage and ensuring the long-term reliability of the system.

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

002445204 Obsolete

Image of *ETITEC B T12 PV 550/12,5 RC

*ETITEC B T12 PV 550/12,5 RC Surge arrester

ETI Code:: 002445204
Function:: SPD
Current type:: DC
Surge arrester type:: T1, T2
Uc Continous Operating Voltage DC:: 550 V
Iimp(10/350) Impulse Current:: 12.5 kA
Nominal Discharge Current (8/20 μs) In:: 20 kA
Remote signalisation:: Yes
Leakage Current:: Yes
Number of modules:: 2
Installation:: PV protection
Built-in depth:: 70 mm
Applied Technology:: MOV
IP rating:: IP20
Catalogue Group:: ETITEC B PV

Product

Net weight of the product: 310 g
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895487876
Basic packaging weight: 0.4 kg
Basic packaging volume: 0.7 dm³

Transport Packaging

Transport packaging quantity: 3 pcs
EAN code for a transport packaging: 3838895487883
Transport packaging weight: 1.2 kg
Transport packaging volume: 2.1 dm³
Pallet quantity: 2,001 pcs
Customs tariff: 85363090

Max. conductor cross section flexible (fine-strand): 25 mm²
Remote signalling: Yes
Max. conductor cross section solid (solid, stranded): 35 mm²
Max. continuous voltage DC: 550 V
Test class: Type 1 + 2
Degree of protection (IP): IP20
Mounting method: DIN rail (top hat rail) 35 mm
Construction size: 4 modular spacing
Lightning impulse current (10/350 µs): 12.5 kA
Specific energy (W/R): 39 kJ/Ohm
Voltage protection level: 2.6 kV
Max. PV-voltage: 458 V
Number of poles: 2
Signalling at the device: Optical
System configuration DC: Yes
