Change-over switches 1-0-2 LBS

Introduction

Load Break Changeover Switches, often referred to as transfer switches, are essential components for managing power distribution in various applications. The LBS..CO series offers a robust and reliable solution for changing over under load between two low voltage power circuits. These manual switches are designed to ensure the safety and continuity of your electrical systems.

LBS 160 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 160 A
Rated operational current Ie AC-21 A/B at 415V: 160 A
Rated Insulation Voltage: 800 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 250 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 250 A
Rated operational current Ie AC-21 A/B at 415V: 250 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 400 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 400 A
Rated operational current Ie AC-21 A/B at 415V: 400 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 630 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 630 A
Rated operational current Ie AC-21 A/B at 415V: 630 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 800 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 800 A
Rated operational current Ie AC-21 A/B at 415V: 800 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 1000 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 1,000 A
Rated operational current Ie AC-21 A/B at 415V: 1,000 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 1250 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 1,250 A
Rated operational current Ie AC-21 A/B at 415V: 1,250 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 1600 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 1,600 A
Rated operational current Ie AC-21 A/B at 415V: 1,600 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 2000 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 2,000 A
Rated operational current Ie AC-21 A/B at 415V: 2,000 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 2500 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 2,500 A
Rated operational current Ie AC-21 A/B at 415V: 2,500 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 3200 3P CO

Class name: Changeover switch
Number of poles: 3
Thermal current Ith: 3,200 A
Rated operational current Ie AC-21 A/B at 415V: 3,200 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 160 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 160 A
Rated operational current Ie AC-21 A/B at 415V: 160 A
Rated Insulation Voltage: 800 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 250 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 250 A
Rated operational current Ie AC-21 A/B at 415V: 250 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 400 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 400 A
Rated operational current Ie AC-21 A/B at 415V: 400 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 630 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 630 A
Rated operational current Ie AC-21 A/B at 415V: 630 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 800 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 800 A
Rated operational current Ie AC-21 A/B at 415V: 800 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 1250 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 1,250 A
Rated operational current Ie AC-21 A/B at 415V: 1,250 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 1600 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 1,600 A
Rated operational current Ie AC-21 A/B at 415V: 1,600 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 2500 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 2,500 A
Rated operational current Ie AC-21 A/B at 415V: 2,500 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO

LBS 3200 4P CO

Class name: Changeover switch
Number of poles: 4
Thermal current Ith: 3,200 A
Rated operational current Ie AC-21 A/B at 415V: 3,200 A
Rated Insulation Voltage: 1,000 V
Max. rated operational voltage (AC): 690 V
Catalogue Group: Load Break Change Over Switch LBS..CO
