* HVL-B 3 3p M10 BOTTOM Fuse switch disconnector
- ETI Code:
- 001696049
- Function:
- NH fuse-switch disconnector size 3, 3-pole, 5-10mm busbars, connection TOP
- Number of poles:
- 3
- Type of Installation:
- Busbar mounting
1 Documents
8 Logistics
Product
- Net weight of the product
- 6.161 kg
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895790082
- Transport packaging weight
- 6.16 kg
- Transport packaging volume
- 14.15 dm³
- Pallet quantity
- 120 pcs
- Customs tariff
- 85365080
4 ETIM
- Mounting method
- Busbar system
- Construction size
- Other
- Number of knife blade fuse holders
- 3
- Number of poles
- 3
