HRN-54 Control relay
- ETI Code:
- 002471416
- Height:
- 90 mm
- Width:
- 18 mm
- Category:
- Over/undervoltage monitoring relay HRN-54, HRN-54N
- Catalogue Group:
- Control and measuring Voltage relays
- Catalogue Subgroup:
- Over/undervoltage monitoring relay
- Type description:
- Over/undervoltage monitoring relay HRN-54, HRN-54N
- Function:
- Monitoring and Control relays
- Supply Voltage:
- 400 V
- Type of Control:
- sequence phase, phase failure
- Number of contacts:
- 1
- Voltage type:
- AC
- Maximum load capacity at AC1:
- 2,500 VA
- Rated current:
- 8 A
- Type of contacts:
- 1xCO
- No. of CO contacts:
- 1
7 Documents
21 Logistics
Product
- Net weight of the product
- 0.07 kg
- Net width
- 17.5 mm
- Net height
- 91.3 mm
- Net depth
- 64.26 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895452195
- Basic packaging weight
- 0.06 kg
- Basic Packaging Dimensions Height
- 70 mm
- Basic Packaging Dimensions Width
- 97 mm
- Basic Packaging Dimensions Depth
- 25 mm
- Basic packaging volume
- 0.17 dm³
Transport Packaging
- Transport packaging quantity
- 10 pcs
- EAN code for a transport packaging
- 3838895452201
- Transport packaging weight
- 0.74 kg
- Transport Packaging Dimensions Height
- 102 mm
- Transport Packaging Dimensions Width
- 284 mm
- Transport Packaging Dimensions Depth
- 75 mm
- Transport packaging volume
- 2.173 dm³
- Pallet quantity
- 4,600 pcs
- Customs tariff
- 85364900
38 ETIM
- Single-phase under voltage possible
- Yes
- Phase failure detection
- Yes
- Width
- 18 mm
- Three-phase under voltage possible
- Yes
- Single-phase hysteresis possible
- Yes
- Max. permitted delay-on energization time
- 10 s
- Min. adjustable delay-on energization time
- 0.1 s
- Voltage type (operating voltage)
- AC
- Max. permitted off-delay time
- 10 s
- Phase sequence monitoring
- Yes
- Voltage type (supply voltage)
- AC
- Min. adjustable off-delay time
- 0.1 s
- Function under voltage detection
- Yes
- Three-phase over voltage possible
- Yes
- Type of voltage measuring range
- AC
- Phase imbalance monitoring
- Yes
- Rated switch current
- 8 A
- Single-phase over voltage possible
- Yes
- Function over voltage detection
- Yes
- Depth
- 64 mm
- Three-phase hysteresis possible
- Yes
- Type of electric connection
- Screw connection
- Number of contacts as change-over contact
- 1
- Height
- 90 mm
- Operating voltage AC 50 Hz(Min)
- 400 V
- Voltage measuring range(Min)
- 300 V
- Operating voltage AC 60 Hz(Min)
- 400 V
- Supply voltage AC 60 Hz(Min)
- 400 V
- Voltage measuring range 2(Min)
- 300 V
- Voltage measuring range 1(Min)
- 420 V
- Supply voltage AC 50 Hz(Min)
- 400 V
- Voltage measuring range 1(Max)
- 500 V
- Supply voltage AC 50 Hz(Max)
- 400 V
- Voltage measuring range(Max)
- 500 V
- Operating voltage AC 60 Hz(Max)
- 400 V
- Operating voltage AC 50 Hz(Max)
- 400 V
- Voltage measuring range 2(Max)
- 380 V
- Supply voltage AC 60 Hz(Max)
- 400 V
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
25 Tags
002471416Control relayHRN-54EVE/ETIRELControl equipmentRelaysRelaysOver/undervoltage monitoring relayOver/undervoltage monitoring relayInternationalAutomation, signaling and control devicesMonitoring and control relays ETIRELType of contacts: 1xCONo. of NC contacts: 0Voltage type: ACNumber of contacts: 1No. of CO contacts: 1Type of Control: phase failure, sequence phase, Umax, UminFunction: Monitoring and Control relaysMaximum load capacity at AC1: 2500 VANo. of NO contacts: 0Supply Voltage: 400 V-400 VRated current: 8 A/8 ADC rated control supply voltage Uc: 0 V-0 VControl relay TOWAR Function: Monitoring and Control relays Supply Voltage: 400 V-400 V Type of Control: phase failure, sequence phase, Umax, Umin Number of contacts: 1 Voltage type: AC Rated current: 8 A/8 A Maximum load capacity at AC1: 2500 VA Type of contacts: 1xCO No. of NC contacts: 0 No. of CO contacts: 1 No. of NO contacts: 0 DC rated control supply voltage Uc: 0 V-0 V
