Hybrid boards (COMBO)

Introduction

DIDO ECG MEDIA COMBO series combines modular power distribution and multimedia equipment housing in a single flush-mounted enclosure. This hybrid solution is designed for modern residential and commercial buildings, providing a central hub for both electrical and communication systems.

Image of ECG42COMBO2/1-I

ECG42COMBO2/1-I

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 3
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 10
Glow wire test (°C): 650 °C

Image of ECG56COMBO3/1-I

ECG56COMBO3/1-I

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 4
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 10
Glow wire test (°C): 650 °C

Image of ECG56COMBO2/2-I

ECG56COMBO2/2-I

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 28/14
Frame size (Nr. of rows): 4
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 13
Glow wire test (°C): 650 °C

Image of ECG70COMBO4/1-I

ECG70COMBO4/1-I

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 10
Glow wire test (°C): 650 °C

Image of ECG70COMBO3/2-I

ECG70COMBO3/2-I

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 28/14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 13
Glow wire test (°C): 650 °C

Image of ECG70COMBO2/3-I

ECG70COMBO2/3-I

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 42/14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 15
Glow wire test (°C): 650 °C

Image of ECG42HCOMBO2/1-I

ECG42HCOMBO2/1-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 3
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 10
Glow wire test (°C): 850 °C

Image of ECG56HCOMBO3/1-I

ECG56HCOMBO3/1-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 4
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 10
Glow wire test (°C): 850 °C

Image of ECG56HCOMBO2/2-I

ECG56HCOMBO2/2-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 28/14
Frame size (Nr. of rows): 4
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 13
Glow wire test (°C): 850 °C

Image of ECG70HCOMBO4/1-I

ECG70HCOMBO4/1-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 10
Glow wire test (°C): 850 °C

Image of ECG70HCOMBO3/2-I

ECG70HCOMBO3/2-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 28/14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 13
Glow wire test (°C): 850 °C

Image of ECG70HCOMBO2/3-I

ECG70HCOMBO2/3-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 42/14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Number of PE/N terminals (connections): 15
Glow wire test (°C): 850 °C

Image of ECG42COMBO2/1-I_FR

ECG42COMBO2/1-I_FR

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 42/14
Frame size (Nr. of rows): 3
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Glow wire test (°C): °C

Image of ECG56COMBO3/1-I_FR

ECG56COMBO3/1-I_FR

Class name: Distribution box
Type of Installation: Flush mounted
Rated current: A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 14
Frame size (Nr. of rows): 4
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Glow wire test (°C): 650 °C

Image of ECG70HCOMBO2/3-I_FR

ECG70HCOMBO2/3-I_FR

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 70/14
Frame size (Nr. of rows): 5
Door (material, color): metal-perforated, white
Enclosure base (material, color): plastic, white
Glow wire test (°C): °C

Image of ECG42HCOMBO3/3-H-I

ECG42HCOMBO3/3-H-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 42/14
Frame size (Nr. of rows): 3
Door (material, color): metal-perforated, white
Number of PE/N terminals (connections): 15
Glow wire test (°C): 850 °C

Image of ECG56HCOMBO4/4-H-I

ECG56HCOMBO4/4-H-I

Class name: Distribution box
Type of Installation: Flush-mounted/hollow wall
Rated current: 63 A
Protection Class: II
IP rating: IP30
No. of modules (total/per row): 56/14
Frame size (Nr. of rows): 4
Door (material, color): metal-perforated, white
Number of PE/N terminals (connections): 20
Glow wire test (°C): 850 °C
