004181132
Obsolete
*NH000 gG 25A/400V korr. Fuse link
- ETI Code:
- 004181132
- Fuse type:
- NH
- Size:
- NH000
- Rated current:
- 25 A
- Time-Current Characteristic:
- gG
- Indicator:
- Top fuse status indicator
- Rated AC voltage:
- 400 V
- Breaking capacity AC:
- 120 kA
- Power dissipation:
- 2.6 W
- Operating joule integral (A2s):
- 5,470
- Prearcing joule integral (A2s):
- 1,200
- Standards:
- IEC 60269-1, IEC 60269-2
- Application:
- For cable protection. Corrosion resistant
15 Logistics
Product
- EAN code for a single product
- 3838400068521
- Net weight of the product
- 120 g
- Net width
- 21 mm
- Net height
- 78.6 mm
- Net depth
- 51.9 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 120 pcs
- EAN code for a transport packaging
- 3838400132598
- Transport packaging weight
- 14.75 kg
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- Transport packaging volume
- 0.017 m³
- Pallet quantity
- 6,240 pcs
- Customs tariff
- 85361050
8 ETIM
- Rated switching capacity AC
- 120 kA
- Voltage type
- AC
- Fuse construction type according to IEC 60269
- NH000
- Rated voltage AC
- 400 V
- Power loss at rated current
- 2.6 W
- Type of fuse status indicator
- Top fuse status indicator
- Rated current
- 25 A
- Utilization category
- gG (cable protection/equipment protection)
ETIM Classification – Version 9.0
3 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
21 Tags
004181132Fuse link*NH000 gG 25A/400V korr.NV/NHLow voltage NH knife-blade fuse-linksNV/NH gG00C KOMBIKorrosionsfest400VInternationalFuse links NHgG CharacteristicSize: NH000Time-Current Characteristic: gGBreaking capacity AC: 120 kAFuse type: NHApplication: For cable protection. Corrosion resistantRated AC voltage: 400 V/400 VRated current: 25 A/25 AIndicator: Top fuse status indicatorFuse link Size: NH000 Rated current: 25 A/25 A Rated AC voltage: 400 V/400 V Time-Current Characteristic: gG
