NH3 gTr 289A/400V/200kVA MET Fuse link

ETI Code:: 004113883
Transformer:: 200 kVA
Fuse type:: NH
Size:: NH3
Rated current:: 289 A
Time-Current Characteristic:: gTr
Indicator:: Top fuse status indicator
Rated AC voltage:: 400 V
Breaking capacity AC:: 25 kA
Power dissipation:: 20 W
Standards:: IEC EN 60269-1
Application:: As metering fuse with strip fuse switch disconnector and fuse switch disconnector

Accessories

Product

Net weight of the product: 650 g
Net width: 66 mm
Net height: 151.5 mm
Net depth: 83.6 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895618898
Basic packaging weight: 0.69 kg
Basic Packaging Dimensions Height: 0.152 m
Basic Packaging Dimensions Width: 0.09 m
Basic Packaging Dimensions Depth: 0.074 m
Basic packaging volume: 0.001 m³

Transport Packaging

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895618904
Transport packaging weight: 8.632 kg
Transport Packaging Dimensions Height: 0.255 m
Transport Packaging Dimensions Width: 0.295 m
Transport Packaging Dimensions Depth: 0.235 m
Transport packaging volume: 0.018 m³
Pallet quantity: 624 pcs
Customs tariff: 85361090

Rated switching capacity AC: 25 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH3
Rated voltage AC: 400
Power loss at rated current: 20 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 289 A
Utilization category: gTr (Transformer protection)

ETIM Classification – Version 9.0
