NHS2XL gPV 250A/1100V DC UL Fuse link

ETI Code:: 004110479
Fuse type:: NH-S
Size:: NH2XL
Rated current:: 250 A
Time-Current Characteristic:: gPV
Indicator:: Top fuse status indicator
Rated DC voltage:: 1100 V
Breaking capacity DC:: 10 kA
L/R:: 2 ms
Power dissipation (0,7xIn):: 19.3 W
Power dissipation:: 44 W
Prearcing joule integral (A2s):: 90,000
Operating joule integral (A2s):: 120,000
UL certificate:: E347771
Standards:: IEC 60269-6, UL 248-19
Application:: Fuse link for DC application

Accessories

Product

Net weight of the product: 1,050 g
Net width: 55 mm
Net height: 198 mm
Net depth: 59 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895693444
Basic packaging weight: 1.05 kg
Basic Packaging Dimensions Height: 0.064 m
Basic Packaging Dimensions Width: 0.222 m
Basic Packaging Dimensions Depth: 0.089 m
Basic packaging volume: 0.001 m³

Transport Packaging

Transport packaging quantity: 12 pcs
EAN code for a transport packaging: 3838895693451
Transport packaging weight: 12.95 kg
Transport Packaging Dimensions Height: 0.255 m
Transport Packaging Dimensions Width: 0.295 m
Transport Packaging Dimensions Depth: 0.235 m
Transport packaging volume: 0.018 m³
Pallet quantity: 624 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 2XL
Power loss at rated current: 44 W
Rated switching capacity DC: 10 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 250 A
Rated voltage DC: 1,100
Utilization category: gPV (photovoltaic protection)
