002442909
ETITEC V T12 440/12,5 4+0 Surge arrester
- ETI Code:
- 002442909
- Function:
- SPD
- Surge arrester type:
- T1, T2
- Uc Continous Operating Voltage AC:
- 440 V
- Iimp(10/350) Impulse Current:
- 12.5 kA
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
- Max. Discharge current Imax, 8/20:
- 50 kA
- Current type:
- AC
- Rated AC voltage:
- 400 V
- Up - Voltage Protection Level:
- 1.7 kV
- Remote signalisation:
- No
- Leakage Current:
- Yes
- Network system:
- IT
- Number of modules:
- 4
- Installation:
- Home and residental building protection
- Built-in depth:
- 68 mm
- IP rating:
- IP20
- Applied Technology:
- MOV
- Catalogue Group:
- ETITEC V
22 Logistics
Product
- EAN code for a single product
- 3838895828075
- Net weight of the product
- 0.49 kg
- Net width
- 72 mm
- Net height
- 95.1 mm
- Net depth
- 66.9 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 2 pcs
- EAN code for a basic packaging
- 3838895857785
- Basic packaging weight
- 1.481 kg
- Basic Packaging Dimensions Height
- 93 mm
- Basic Packaging Dimensions Width
- 105 mm
- Basic Packaging Dimensions Depth
- 183 mm
- Basic packaging volume
- 1.787 dm³
Transport Packaging
- Transport packaging quantity
- 16 pcs
- EAN code for a transport packaging
- 3838895828082
- Transport packaging weight
- 12.48 kg
- Transport Packaging Dimensions Height
- 220 mm
- Transport Packaging Dimensions Width
- 220 mm
- Transport Packaging Dimensions Depth
- 460 mm
- Transport packaging volume
- 22.264 dm³
- Pallet quantity
- 384 pcs
- Customs tariff
- 85354000
12 ETIM
- Nominal voltage AC
- 400 V
- Test class
- Type 1 + 2
- Degree of protection (IP)
- IP20
- Mounting method
- DIN rail (top hat rail) 35 mm
- Lightning impulse current (10/350 µs)
- 12.5 kA
- Specific energy (W/R)
- 40 kJ/Ohm
- System configuration TN-S
- Yes
- Voltage protection level
- 1.7 kV
- Number of poles
- 4
- Signalling at the device
- Optical
- System configuration IT
- Yes
- Max. continuous voltage AC
- 440 V
ETIM Classification – Version 9.0
