002471102
ETS-16b Twilight switch
- ETI Code:
- 002471102
- Type of Installation:
- Front mounting
- Color:
- Grey
- Catalogue Group:
- Twillight and staircase switches
- Type description:
- Twilight switch in IP65 ETS-16b
- Catalogue Subgroup:
- Twilight switch IP65
- Function:
- Monitoring and Control relays
- Supply Voltage:
- 180-230 V
- Luminous flux:
- 2-50 lx
- Number of contacts:
- 1
- Rated current:
- 16 A
- Maximum load capacity at AC1:
- 4,000 VA
- Voltage type:
- AC
- Category:
- Twillight and staircase switches
- Type of contacts:
- 1xNO
- No. of NO contacts:
- 1
5 Documents
14 Logistics
Product
- Net depth
- 30.1 mm
- Net weight of the product
- 0.15 kg
- Net width
- 67.5 mm
- Net height
- 68.5 mm
- Stock unit of measure
- pcs
Basic Packaging
- EAN code for a basic packaging
- 5904722934672
- Basic packaging weight
- 0.07 kg
- Basic packaging quantity
- 1 pcs
Transport Packaging
- Transport packaging weight
- 0.428 kg
- Transport packaging volume
- 0.696 dm³
- Transport packaging quantity
- 6 pcs
- Customs tariff
- 85364900
- EAN code for a transport packaging
- 3838895792314
- Pallet quantity
- 9,000 pcs
19 ETIM
- Width
- 48 mm
- Engaging brightness(Min)
- 2 lx
- Mounting method
- Surface mounted
- Switching-on delay
- 20 s
- Nominal voltage
- 230 V
- Material quality
- Thermoplastic
- Switch-off delay
- 20 s
- Type of sensor
- Built-in light sensor
- Switching-off brightness(Max)
- 50 lx
- Max. switching current (resistive load)
- 16 A
- Halogen free
- Yes
- Switching-off brightness(Min)
- 50 lx
- Depth
- 29 mm
- Colour
- Grey
- Suitable for degree of protection (IP)
- IP65
- Engaging brightness(Max)
- 2 lx
- Contacts
- 1 make contact (NO)
- Material
- Plastic
- Height
- 69 mm
ETIM Classification – Version 9.0
