NH fuse-links with gPV (general Photovoltaic) characteristics are specifically designed for protecting photovoltaic (PV) systems against overcurrent conditions. These fuse-links ensure the safety and reliability of solar power installations by isolating fault currents, preventing damage to PV panels, inverters, and associated wiring.

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

004110603 Obsolete

Image of *NHS3L gPV 350A/1500V DC

*NHS3L gPV 350A/1500V DC Fuse link

ETI Code:: 004110603
Fuse type:: NH
Size:: NH3L
Rated current:: 350 A
Time-Current Characteristic:: gPV
Indicator:: Top fuse status indicator
Rated DC voltage:: 1500 V
Breaking capacity DC:: 30 kA
L/R:: 3 ms
Power dissipation (0,7xIn):: 25.5 W
Power dissipation:: 63 W
Prearcing joule integral (A2s):: 140,000
Operating joule integral (A2s):: 200,000
UL certificate:: E347771
Standards:: IEC 60269-6, UL 248-19
Application:: Fuse-link for DC application

Product

Net weight of the product: 1,980 g
Net width: 73 mm
Net height: 198 mm
Net depth: 73 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895737490
Basic packaging weight: 1.36 kg
Basic packaging volume: 1.39 dm³

Transport Packaging

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895737506
Transport packaging weight: 12.475 kg
Transport packaging volume: 16.98 dm³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Voltage type: DC
Rated switching capacity DC: 30 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 350 A
Rated voltage DC: 1,500 V
Utilization category: gPV (photovoltaic protection)

ETIM Classification – Version 9.0
