004110615 Obsolete

*NHU3L gPV 250A/1500V DC Fuse link

ETI Code:: 004110615
Fuse type:: NH-U
Size:: NH3L
Rated current:: 250 A
Time-Current Characteristic:: gPV
Indicator:: Top fuse status indicator
Rated DC voltage:: 1500 V
Breaking capacity DC:: 30 kA
L/R:: 3 ms
Power dissipation:: 47 W
UL certificate:: E347771
Standards:: IEC 60269-6, UL 248-19
Application:: Fuse link for DC application. Applied in fuse base PK 3L 1500V

Product

Net weight of the product: 1,980 g
Net width: 73 mm
Net height: 198 mm
Net depth: 73 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895737575
Basic packaging weight: 2.04 kg
Basic Packaging Dimensions Height: 74 mm
Basic Packaging Dimensions Width: 220 mm
Basic Packaging Dimensions Depth: 91 mm
Basic packaging volume: 1.481 dm³

Transport Packaging

Transport packaging quantity: 9 pcs
EAN code for a transport packaging: 3838895737582
Transport packaging weight: 18.71 kg
Transport Packaging Dimensions Height: 0.25 m
Transport Packaging Dimensions Width: 0.235 m
Transport Packaging Dimensions Depth: 0.295 m
Transport packaging volume: 0.017 m³
Pallet quantity: 468 pcs
Customs tariff: 85351000

Voltage type: DC
Fuse construction type according to IEC 60269: 3L
Power loss at rated current: 47 W
Rated switching capacity DC: 30 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 250 A
Rated voltage DC: 1,500
Utilization category: gPV (photovoltaic protection)

ETIM Classification – Version 9.0
