002470074
Obsolete
*CRM-82TO UNI Time relay
- ETI Code:
- 002470074
- Type of Installation:
- TH 35
- Category:
- Delay OFF without supply voltage CRM-82TO
- Catalogue Group:
- Time relay (Analog)
- Time range:
- 0.1 s - 10 min
- Type description:
- Delay OFF without supply voltage CRM-82TO
- Catalogue Subgroup:
- Delay OFF without supply voltage
- Voltage type:
- AC/DC
- Number of contacts:
- 2
- No. of CO contacts:
- 1
- Function:
- Time relay
- Maximum load capacity at AC1:
- 2,000 VA
- Number of Functions:
- 2
- Supply Voltage:
- 12-240 V
- Rated current:
- 8 A
7 Documents
15 Logistics
Product
- Net depth
- 59.67 mm
- Net weight of the product
- 0.065 kg
- Net width
- 17.5 mm
- Net height
- 91.3 mm
- Stock unit of measure
- pcs
Basic Packaging
- EAN code for a basic packaging
- 3838895423638
- Basic packaging weight
- 0.09 kg
- Basic packaging volume
- 0.11 dm³
- Basic packaging quantity
- 1 pcs
Transport Packaging
- Transport packaging weight
- 1 kg
- Transport packaging volume
- 1.6 dm³
- Transport packaging quantity
- 10 pcs
- Customs tariff
- 85364900
- EAN code for a transport packaging
- 3838895423645
- Pallet quantity
- 8,000 pcs
12 ETIM
- 1st interval unit
- Seconds/minutes
- Mounting method
- DIN rail
- Supply voltage(Min)
- 12 V
- Voltage type (supply voltage)
- AC/DC
- 1st interval(Min)
- 0.1
- Type of excitation
- Digital with multi function
- Supply voltage(Max)
- 240 V
- Built-in height
- 65 mm
- Number of changeover switches
- 2
- 1st interval(Max)
- 10
- Function
- Release-delay
- Width in number of modular spacings
- 1
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
21 Tags
002470074Time relay*CRM-82TO UNIEVE/ETIRELControl equipmentRelaysRelaysDelay OFF without supply voltageDelay OFF without supply voltageInternationalAutomation, signaling and control devicesTimers and digital time relays ETIRELVoltage type: AC/DCNumber of contacts: 2No. of CO contacts: 1Function: Time relayMaximum load capacity at AC1: 2000 VANumber of Functions: 2Supply Voltage: 12 V-240 VRated current: 8 A/8 ATime relay TOWAR Voltage type: AC/DC Number of contacts: 2 No. of CO contacts: 1 Function: Time relay Maximum load capacity at AC1: 2000 VA Supply Voltage: 12 V-240 V Rated current: 8 A/8 A
