Surge arrester ETITEC B-PV 1000/12,5 (10/350 002445203 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 002445203
- Description:
- *ETITEC B-PV 1000/12,5 (10/350
- Class name:
- Surge arrester
- Current type:
- DC
- Usage (IEC/VDE):
- I, II / B, C
- Function:
- SPD
- Type:
- T1, T2
- Number of poles:
- 2
- Size:
- 4 modules
- IP rating:
- IP20
- Mounting:
- DIN rail (top hat rail) 35 mm
- Catalogue Group:
- ETITEC B PV
- Number of modules:
- 2
- Leakage current:
- YES
- Applied technology:
- MOV
- Built-in depth (mm):
- 70
- Iimp(10/350) impulse current (kA):
- 12,5
- Max. discharge current Imax, 8/20 (kA):
- 40
- Remote signalisation:
- NO
- Installation:
- PV protection
Documents
Logistic Data
Product
- Customs tariff
- 85363090
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895487852
- Basic packaging weight
- 0.6 kg
Transport packaging
- Transport packaging quantity
- 3
- EAN code for a transport packaging
- 3838895487869
- Transport packaging weight
- 1.8 kg
- Pallet quantity
- 1332
ETIM Clasification
- Classification
- EC001457
- Class name
- Combined arrester for power supply systems
- System configuration DC
- Yes
- System configuration IT
- No
- System configuration TN
- No
- System configuration TN-C
- No
- System configuration TN-C-S
- No
- System configuration TN-S
- No
- System configuration TT
- No
- System configuration other
- No
- Number of poles
- 2
- Lightning impulse current (10/350 µs)
- 12,5
- Max. continuous voltage DC
- 1000
- Max. PV-voltage
- 833
- Voltage protection level
- 2,6
- Specific energy (W/R)
- 39
- Max. conductor cross section solid (solid, stranded)
- 35
- Max. conductor cross section flexible (fine-strand)
- 25
- Mounting method
- DIN rail (top hat rail) 35 mm
- Construction size
- 6 modular spacing
- Remote signalling
- No
- Signalling at the device
- Optical
- Test class
- Type 1 + 2
- Exhausting
- No
- Integrated backup fuse
- No
- Degree of protection (IP)
- IP20
