Motor Protective circuit breaker

Items: 0
004648001
1
MPE25-0,16
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,1 - 0,16
Short-circuit release Irm (A): 2,08
Rated operation power at AC3 (kW):
Tripping class (IEC 60947-4-1): Class 10:
004648002
1
MPE25-0,25
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,16 - 0,25
Short-circuit release Irm (A): 3,25
Rated operation power at AC3 (kW): 0,06
Tripping class (IEC 60947-4-1): Class 10:
004648003
1
MPE25-0,40
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,25 - 0,4
Short-circuit release Irm (A): 5,2
Rated operation power at AC3 (kW): 0,09
Tripping class (IEC 60947-4-1): Class 10:
004648004
1
MPE25-0,63
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,4 - 0,63
Short-circuit release Irm (A): 8,2
Rated operation power at AC3 (kW): 0,12
Tripping class (IEC 60947-4-1): Class 10:
004648005
1
MPE25-1,0
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,63 - 1,0
Short-circuit release Irm (A): 13
Rated operation power at AC3 (kW): 0,25
Tripping class (IEC 60947-4-1): Class 10:
004648006
1
MPE25-1,6
Class name: Mot.protec.circuit breaker
Current setting range (A): 1,0 - 1,6
Short-circuit release Irm (A): 20,8
Rated operation power at AC3 (kW): 0,37
Tripping class (IEC 60947-4-1): Class 10:
004648007
1
MPE25-2,5
Class name: Mot.protec.circuit breaker
Current setting range (A): 1,6 - 2,5
Short-circuit release Irm (A): 32,5
Rated operation power at AC3 (kW): 0,75
Tripping class (IEC 60947-4-1): Class 10:
004648008
1
MPE25-4,0
Class name: Mot.protec.circuit breaker
Current setting range (A): 2,5 - 4,0
Short-circuit release Irm (A): 52
Rated operation power at AC3 (kW): 1,5
Tripping class (IEC 60947-4-1): Class 10:
004648009
1
MPE25-6,3
Class name: Mot.protec.circuit breaker
Current setting range (A): 4,0 - 6,3
Short-circuit release Irm (A): 82
Rated operation power at AC3 (kW): 2,2
Tripping class (IEC 60947-4-1): Class 10:
004648010
1
MPE25-10
Class name: Mot.protec.circuit breaker
Current setting range (A): 6,3 - 10
Short-circuit release Irm (A): 130
Rated operation power at AC3 (kW): 4,5
Tripping class (IEC 60947-4-1): Class 10:
004648012
1
MPE25-20
Class name: Mot.protec.circuit breaker
Current setting range (A): 16 - 20
Short-circuit release Irm (A): 260
Rated operation power at AC3 (kW): 9,2
Tripping class (IEC 60947-4-1): Class 10:
004648013
1
MPE25-25
Class name: Mot.protec.circuit breaker
Current setting range (A): 20 - 25
Short-circuit release Irm (A): 325
Rated operation power at AC3 (kW): 11
Tripping class (IEC 60947-4-1): Class 10:
004648014
1
MPE25-32
Class name: Mot.protec.circuit breaker
Current setting range (A): 25 - 32
Short-circuit release Irm (A): 416
Rated operation power at AC3 (kW): 15
Tripping class (IEC 60947-4-1): Class 10:
004648011
1
MPE25-16
Class name: Mot.protec.circuit breaker
Current setting range (A): 10-16
Short-circuit release Irm (A): 208
Rated operation power at AC3 (kW): 7,5
Tripping class (IEC 60947-4-1): Class 10:
004600010
1
MS25-0,16
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,1 - 0,16
Short-circuit release Irm (A): 1,9
Rated operation power at AC3 (kW): 0,02
Tripping class (IEC 60947-4-1): Class 10:
004600020
1
MS25-0,25
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,16 - 0,25
Short-circuit release Irm (A): 2,6
Rated operation power at AC3 (kW): 0,06
Tripping class (IEC 60947-4-1): Class 10:
004600030
1
MS25-0,4
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,25 - 0,4
Short-circuit release Irm (A): 4,4
Rated operation power at AC3 (kW): 0,09
Tripping class (IEC 60947-4-1): Class 10:
004600040
1
MS25-0,63
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,4 - 0,63
Short-circuit release Irm (A): 8
Rated operation power at AC3 (kW): 0,12
Tripping class (IEC 60947-4-1): Class 10:
004600050
1
MS25-1
Class name: Mot.protec.circuit breaker
Current setting range (A): 0,63 - 1,0
Short-circuit release Irm (A): 11
Rated operation power at AC3 (kW): 0,18…0,25
Tripping class (IEC 60947-4-1): Class 10:
004600060
1
MS25-1,6
Class name: Mot.protec.circuit breaker
Current setting range (A): 1,0 - 1,6
Short-circuit release Irm (A): 19
Rated operation power at AC3 (kW): 0,37…0,55
Tripping class (IEC 60947-4-1): Class 10:
004600070
1
MS25-2,5
Class name: Mot.protec.circuit breaker
Current setting range (A): 1,6 - 2,5
Short-circuit release Irm (A): 30
Rated operation power at AC3 (kW): 0,75…1,1
Tripping class (IEC 60947-4-1): Class 10:
004600080
1
MS25-4
Class name: Mot.protec.circuit breaker
Current setting range (A): 2,5 - 4,0
Short-circuit release Irm (A): 42
Rated operation power at AC3 (kW): 1,1…1,5
Tripping class (IEC 60947-4-1): Class 10:
004600090
1
MS25-6,3
Class name: Mot.protec.circuit breaker
Current setting range (A): 4,0 - 6,3
Short-circuit release Irm (A): 69
Rated operation power at AC3 (kW): 2,2…2,5
Tripping class (IEC 60947-4-1): Class 10:
004600100
1
MS25-10
Class name: Mot.protec.circuit breaker
Current setting range (A): 6,3 - 10
Short-circuit release Irm (A): 110
Rated operation power at AC3 (kW): 3…4
Tripping class (IEC 60947-4-1): Class 10:
004600110
1
MS25-16
Class name: Mot.protec.circuit breaker
Current setting range (A): 10,0 - 16,0
Short-circuit release Irm (A): 210
Rated operation power at AC3 (kW): 5…5,7
Tripping class (IEC 60947-4-1): Class 10:
004600120
1
MS25-20
Class name: Mot.protec.circuit breaker
Current setting range (A): 16,0 - 20,0
Short-circuit release Irm (A): 220
Rated operation power at AC3 (kW): 9
Tripping class (IEC 60947-4-1): Class 10:
004600320
1
MS25-25
Class name: Mot.protec.circuit breaker
Current setting range (A): 20,0 - 25,0
Short-circuit release Irm (A): 330
Rated operation power at AC3 (kW): 11…12,5
Tripping class (IEC 60947-4-1): Class 10:
004600530
1
MST25-0,4
Class name: Mot.protec.circuit breaker
Current setting range (A):
Short-circuit release Irm (A):
Rated operation power at AC3 (kW):
Tripping class (IEC 60947-4-1): Class 10:
004600540
1
MST25-0,63
Class name: Mot.protec.circuit breaker
Current setting range (A):
Short-circuit release Irm (A):
Rated operation power at AC3 (kW):
Tripping class (IEC 60947-4-1): Class 10:
004600550
1
MST25-1,0
Class name: Mot.protec.circuit breaker
Current setting range (A):
Short-circuit release Irm (A):
Rated operation power at AC3 (kW):
Tripping class (IEC 60947-4-1): Class 10:
