SYSTEM C

Items: 0
002625005
CH10 aR 6A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 6
Rated AC voltage (V): 600
002625006
CH10 aR 8A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 8
Rated AC voltage (V): 600
002625007
CH10 aR 10A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 10
Rated AC voltage (V): 600
002625008
CH10 aR 12A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 12
Rated AC voltage (V): 600
002625009
CH10 aR 16A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 16
Rated AC voltage (V): 600
002625011
CH10 aR 20A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 20
Rated AC voltage (V): 600
002625013
CH10 aR 25A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 25
Rated AC voltage (V): 600
002625015
CH 10x38 aR 32A / 600V
Class name: Fuse link
Type: CH
Size: CH10
Rated current (A): 32
Rated AC voltage (V): 600
002635007
CH14 aR 10A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 10
Rated AC voltage (V): 690
002635008
CH14 aR 12A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 12
Rated AC voltage (V): 690
002635009
CH14 aR 16A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 16
Rated AC voltage (V): 690
002635011
CH14 aR 20A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 20
Rated AC voltage (V): 690
002635013
CH14 aR 25A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 25
Rated AC voltage (V): 690
002635015
CH14 aR 32A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 32
Rated AC voltage (V): 690
002635017
CH14 aR 40A / 600V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 40
Rated AC voltage (V): 600
002635019
CH14 aR 50A / 500V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 50
Rated AC voltage (V): 500
002645011
CH22 aR 20A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 20
Rated AC voltage (V): 690
002645013
CH22 aR 25A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 25
Rated AC voltage (V): 690
002645015
CH22 aR 32A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 32
Rated AC voltage (V): 690
002645017
CH22 aR 40A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 40
Rated AC voltage (V): 690
002645019
CH22 aR 50A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 50
Rated AC voltage (V): 690
002645021
CH22 aR 63A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 63
Rated AC voltage (V): 690
002645023
CH22 aR 80A / 600V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 80
Rated AC voltage (V): 600
002645025
CH22 aR 100A / 500V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 100
Rated AC voltage (V): 500
002635107
CH/P14 aR 10A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 10
Rated AC voltage (V): 690
002635108
CH/P14 aR 12A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 12
Rated AC voltage (V): 690
002635109
CH/P14 aR 16A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 16
Rated AC voltage (V): 690
002635111
CH/P14 aR 20A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 20
Rated AC voltage (V): 690
002635113
CH/P14 aR 25A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 25
Rated AC voltage (V): 690
002635115
CH/P14 aR 32A / 690V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 32
Rated AC voltage (V): 690
002635117
CH/P14 aR 40A / 600V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 40
Rated AC voltage (V): 600
002635119
CH/P14 aR 50A / 500V
Class name: Fuse link
Type: CH
Size: CH14
Rated current (A): 50
Rated AC voltage (V): 500
002645111
CH/P22 aR 20A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 20
Rated AC voltage (V): 690
002645113
CH/P22 aR 25A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 25
Rated AC voltage (V): 690
002645115
CH/P22 aR 32A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 32
Rated AC voltage (V): 690
002645117
CH/P22 aR 40A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 40
Rated AC voltage (V): 690
002645119
CH/P22 aR 50A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 50
Rated AC voltage (V): 690
002645121
CH/P22 aR 63A / 690V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 63
Rated AC voltage (V): 690
002645123
CH/P22 aR 80A / 600V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 80
Rated AC voltage (V): 600
002645125
CH/P22 aR 100A / 500V
Class name: Fuse link
Type: CH
Size: CH22
Rated current (A): 100
Rated AC voltage (V): 500
