Fuse - base PP D01 K 1p 002221015 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 002221015
- Description:
- *PP D01 K 1p
- Class name:
- Fuse - base
- Mounting type:
- TH 35
- Product group:
- LV-fuse base
- Size:
- D01
- Number of poles:
- 1
- Rated current (A):
- 25
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400029874
- Net weight of the product
- 0.075 kg
- Customs tariff
- 85389099
Basic packaging
- Basic packaging quantity
- 15
- EAN code for a basic packaging
- 3838895139096
- Basic packaging weight
- 1.12 kg
Transport packaging
- Transport packaging quantity
- 180
- EAN code for a transport packaging
- 3838895716068
- Transport packaging weight
- 13.9 kg
- Pallet quantity
- 4320
ETIM Clasification
- Classification
- EC001644
- Class name
- D0-system fuse base
- Number of poles
- 1
- Construction size
- D01
- Material
- Plastic
- Mounting method
- DIN rail
- Rated voltage
- 400V
- Rated current
- 25A
Images & Diagrams
