Fuse link CH14x51 gG 25A/690V 002630013 Obsolete
This product is obsolete and has been replaced with CH14x51 gG 25A/690V.
Compare products
Specifications
- ETI Code:
- 002630013
- Description:
- *CH14x51 gG 25A/690V
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- CH
- Size:
- 14x51
- Rated current (A):
- 25A
- Rated AC voltage (V):
- 690V
- Characteristics:
- gG
- Breaking capacity AC (kA):
- 80kA
- Application:
- For cable protection
- Power dissipation (W):
- 4.2W
- Standards:
- IEC 60269-1,IEC 60269-2
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895581420
- Net weight of the product
- 18.75 g
- Customs tariff
- 85361050
- logis_net_width
- 14 mm
- logis_net_height
- 51 mm
- logis_net_depth
- 14 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895138938
- Basic packaging weight
- 0.186 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895165859
- Transport packaging weight
- 9.8 kg
- Pallet quantity
- 85000
*CH14x51 gG 25A/690V
