Fuse link CH14x51/P gG 4A/500V 006711005
Specifications
- ETI Code:
- 006711005
- Description:
- CH14x51/P gG 4A/500V
- Class name:
- Fuse link
- Type:
- CH
- Size:
- 14x51
- Rated current (A):
- 4A
- Rated AC voltage (V):
- 500V
- Characteristics:
- gG
- Breaking capacity AC (kA):
- 80kA
- Application:
- For cable protection
- Indicator:
- Striker pin status indicator
- Power dissipation (W):
- 1W
- Standards:
- IEC 60269-1,IEC 60269-2
Documents
Logistic Data
Product
- Net weight of the product
- 0.023 kg
- Customs tariff
- 85361010
- logis_net_width
- 14 mm
- logis_net_height
- 59 mm
- logis_net_depth
- 14 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 8024873004615
- Basic packaging weight
- 0.21 kg
Transport packaging
- Transport packaging quantity
- 50
- EAN code for a transport packaging
- 8024873060550
- Transport packaging weight
- 1.01 kg
- Pallet quantity
- 79350
ETIM Clasification
- Classification
- EC002704
- Class name
- Miniature fuse
- Rated current
- 4A
CH14x51/P gG 4A/500V
