Changeover switch LBS 400 4P CO 004661563
Specifications
- ETI Code:
- 004661563
- Description:
- LBS 400 4P CO
- Class name:
- Changeover switch
- Number of poles:
- 4
- Thermal current Ith (A):
- 400
- Rated operational current Ie AC-21 A/B at 415V (A):
- 400
- Rated insulation voltage (V):
- 1000
- Max. rated operational voltage (V AC):
- 690
- Mounting:
- Panel mounted
Documents
Logistic Data
Product
- Customs tariff
- 85365080
- logis_net_width
- 312 mm
- logis_net_height
- 170 mm
- logis_net_depth
- 175 mm
Transport packaging
- Transport packaging quantity
- 1
- EAN code for a transport packaging
- 3838895719762
- Transport packaging weight
- 5.868 kg
- Pallet quantity
- 45
ETIM Clasification
- Classification
- EC000216
- Class name
- Switch disconnector
- Version as main switch
- Yes
- Version as maintenance-/service switch
- Yes
- Version as safety switch
- Yes
- Max. rated operation voltage Ue AC
- 415V
- Rated permanent current Iu
- 400A
- Rated operation power at AC-23, 400 V
- 280kW
- Number of poles
- 4
- Motor drive integrated
- No
- Suitable for floor mounting
- Yes
- Type of control element
- Toggle
