Fuses for railway applications

Items: 0
004735601
1
S2M/394/100A/4000V DC
Class name: Fuse link
Size: NH2
Type: NH
Rated current (A): 100
Rated DC voltage (V): 4000
004735602
1
S2M/394/125A 4000V DC
Class name: Fuse link
Size: NH2
Type: NH
Rated current (A): 125
Rated DC voltage (V): 4000
004735603
1
S2M/394/160A 4000V DC
Class name: Fuse link
Size: NH2
Type: NH
Rated current (A): 160
Rated DC voltage (V): 4000
004735604
1
S2M/394/200A 4000V DC
Class name: Fuse link
Size: NH2
Type: NH
Rated current (A): 200
Rated DC voltage (V): 4000
004735605
1
S2M/394/250A 4000V DC
Class name: Fuse link
Size: NH2
Type: NH
Rated current (A): 250
Rated DC voltage (V): 4000
004735555
1
DB1kV TYP:OH15NN1000V/7,5A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 7,5
Rated DC voltage (V): 1000
004735556
1
DB1kV TYP:OH17NN1000V/10A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 10
Rated DC voltage (V): 1000
004735557
1
DB1kV TYP:OH22NN1000V/16A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 16
Rated DC voltage (V): 1000
004735558
1
DB1kV TYP:OH24NN1000V/20A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 20
Rated DC voltage (V): 1000
004735559
1
DB1kV TYP:OH26NN1000V/25A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 25
Rated DC voltage (V): 1000
004735560
1
DB1kV TYP:OH27NN1000V/30A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 30
Rated DC voltage (V): 1000
004735561
1
DB1kV TYP:OH31NN1000V/35A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 35
Rated DC voltage (V): 1000
004735562
1
DB1kV TYP:OH34NN1000V/40A
Class name: Fuse link
Size: DB1
Type: DB
Rated current (A): 40
Rated DC voltage (V): 1000
004735564
1
DB1kV TYP:OH36NP1000V/50A
Class name: Fuse link
Size: DB2
Type: DB
Rated current (A): 50
Rated DC voltage (V): 1000
004735566
1
DB1kV TYP:OH37PP1000V/60A
Class name: Fuse link
Size: DB3
Type: DB
Rated current (A): 60
Rated DC voltage (V): 1000
004735567
1
DB1,5kVTYP:OK15PP1500V7,5A
Class name: Fuse link
Size: DB3
Type: DB
Rated current (A): 7,5
Rated DC voltage (V): 1500
004735568
1
DB1,5kVTYP:OK24PP1500V/20A
Class name: Fuse link
Size: DB3
Type: DB
Rated current (A): 20
Rated DC voltage (V): 1500
004735571
1
DB1kV TYP:OH39PQ1000V/70A
Class name: Fuse link
Size: DB4
Type: DB
Rated current (A): 70
Rated DC voltage (V): 1000
004735573
1
DB TYP:OK 34LP 1500V/40A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 40
Rated DC voltage (V): 1500
004735575
1
DB1,5kVTYP:OK37LP1500V/60A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 60
Rated DC voltage (V): 1500
004735576
1
DB3kV TYP:ON17RP3000V/10A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 10
Rated DC voltage (V): 3000
004735577
1
DB3kV TYP:ON21RP3000V/15A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 15
Rated DC voltage (V): 3000
004735578
1
DB3kV TYP:ON24RP3000V/20A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 20
Rated DC voltage (V): 3000
004735580
1
DB3kV TYP:ON27RP3000V/30A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 30
Rated DC voltage (V): 3000
004735581
2
DB3kV TYP:ON36RP3000V/50A
Class name: Fuse link
Size: DB5
Type: DB
Rated current (A): 50
Rated DC voltage (V): 3000
004735583
1
DB1kV TYP:OH43TQ1000V/100A
Class name: Fuse link
Size: DB6
Type: DB
Rated current (A): 100
Rated DC voltage (V): 1000
004735584
1
DB1kV TYP:OH45TQ1000V/125A
Class name: Fuse link
Size: DB6
Type: DB
Rated current (A): 125
Rated DC voltage (V): 1000
004735585
1
DB3kV TYP:ON17TQ3000V/10A
Class name: Fuse link
Size: DB6
Type: DB
Rated current (A): 10
Rated DC voltage (V): 3000
004735586
1
DB3kV TYP:ON24TQ3000V/20A
Class name: Fuse link
Size: DB6
Type: DB
Rated current (A): 20
Rated DC voltage (V): 3000
004735587
1
DB3kV TYP:ON27TQ3000V/30A
Class name: Fuse link
Size: DB6
Type: DB
Rated current (A): 30
Rated DC voltage (V): 3000
{"records":[{"ID":"42803","eti_code":"004735601","descr":"S2M\/394\/100A\/4000V DC","seo_name":"Fuse link S2M\/394\/100A\/4000V NH2 NH 100A 4000V aR 15ms","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"3.6","weight_em":"kg","basic_packaging":null,"shipping_packaging":null,"stock_type":null,"file_link":"\/images\/product_db\/levels\/en-GB\/4285_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735601|Fuse link, S2M\/394\/100A\/4000V DC|Special fuses|Fuses for railway applications|Railway fuses|NH2 S\/394\/ DC 4000V aR|NH2 S\/394\/ DC 4000V aR|with centre trip indicator for microswitch MK|Special purpose fuses|Fuses for railway applications|S2M\/394\/100A\/400|Rated current 100A|Type NH|Size NH2|Product group Special purpose fuses|Product subgroup railway|Characteristics aR|Rated DC voltage 4000V|Dimensions S394mm|Indicator Centre trip indicator for MK|Breaking capacity DC 30kA|Power dissipation 58W|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards IEC 60269-4 , IEC 60077-5|Operating joule integral 20.000A2s|L\/R 15ms|Prearcing joule integral 2.300A2s|Application Fuse link for DC link protection of railway inverter.|Fuse link S2M\/394\/100A\/4000V NH2 NH 100A 4000V aR 15ms|","stockammount":"0","stockstatus":"0","rated_current":"100","type":"NH","size":"NH2","charact":"aR","rated_dc_voltage":"4000","dimensions":"S394mm","indicator":"Centre trip indicator for MK","breaking_capacity_dc":"30","pd_w":"58","Standards":"IEC 60269-4 , IEC 60077-5","Power_dissip_07":"","Operating_joule":"20.000","L_R":"15","Prearcing_joule":"2.300","Application":"Fuse link for DC link protection of railway inverter.","UL_certificate":"","price":"1764.0688","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735601-fuse-link-s2m-394-100a-4000v-nh2-nh-100a-4000v-ar-15ms"},{"ID":"42804","eti_code":"004735602","descr":"S2M\/394\/125A 4000V DC","seo_name":"Fuse link S2M\/394\/125A NH2 NH 125A 4000V aR 15ms","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"3.6","weight_em":"kg","basic_packaging":null,"shipping_packaging":null,"stock_type":null,"file_link":"\/images\/product_db\/levels\/en-GB\/4285_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735602|Fuse link, S2M\/394\/125A 4000V DC|Special fuses|Fuses for railway applications|Railway fuses|NH2 S\/394\/ DC 4000V aR|NH2 S\/394\/ DC 4000V aR|with centre trip indicator for microswitch MK|Special purpose fuses|Fuses for railway applications|S2M\/394\/125A 400|Rated current 125A|Type NH|Size NH2|Product group Special purpose fuses|Product subgroup railway|Characteristics aR|Rated DC voltage 4000V|Dimensions S394mm|Indicator Centre trip indicator for MK|Breaking capacity DC 30kA|Power dissipation 82W|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards IEC 60269-4 , IEC 60077-5|Operating joule integral 33.000A2s|L\/R 15ms|Prearcing joule integral 3.700A2s|Application Fuse link for DC link protection of railway inverter.|Fuse link S2M\/394\/125A NH2 NH 125A 4000V aR 15ms|","stockammount":"0","stockstatus":"0","rated_current":"125","type":"NH","size":"NH2","charact":"aR","rated_dc_voltage":"4000","dimensions":"S394mm","indicator":"Centre trip indicator for MK","breaking_capacity_dc":"30","pd_w":"82","Standards":"IEC 60269-4 , IEC 60077-5","Power_dissip_07":"","Operating_joule":"33.000","L_R":"15","Prearcing_joule":"3.700","Application":"Fuse link for DC link protection of railway inverter.","UL_certificate":"","price":"1764.0688","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735602-fuse-link-s2m-394-125a-nh2-nh-125a-4000v-ar-15ms"},{"ID":"42805","eti_code":"004735603","descr":"S2M\/394\/160A 4000V DC","seo_name":"Fuse link S2M\/394\/160A NH2 NH 160A 4000V aR 15ms","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"3.6","weight_em":"kg","basic_packaging":"","shipping_packaging":"","stock_type":"","file_link":"\/images\/product_db\/levels\/en-GB\/4285_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735603|Fuse link, S2M\/394\/160A 4000V DC|Special fuses|Fuses for railway applications|Railway fuses|NH2 S\/394\/ DC 4000V aR|NH2 S\/394\/ DC 4000V aR|with centre trip indicator for microswitch MK|Special purpose fuses|Fuses for railway applications|S2M\/394\/160A 400|Rated current 160A|Type NH|Size NH2|Product group Special purpose fuses|Product subgroup railway|Characteristics aR|Rated DC voltage 4000V|Dimensions S394mm|Indicator Centre trip indicator for MK|Breaking capacity DC 30kA|Power dissipation 100W|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards IEC 60269-4 , IEC 60077-5|Operating joule integral 55.000A2s|L\/R 15ms|Prearcing joule integral 5.800A2s|Application Fuse link for DC link protection of railway inverter.|Fuse link S2M\/394\/160A NH2 NH 160A 4000V aR 15ms|","stockammount":"0","stockstatus":"0","rated_current":"160","type":"NH","size":"NH2","charact":"aR","rated_dc_voltage":"4000","dimensions":"S394mm","indicator":"Centre trip indicator for MK","breaking_capacity_dc":"30","pd_w":"100","Standards":"IEC 60269-4 , IEC 60077-5","Power_dissip_07":"","Operating_joule":"55.000","L_R":"15","Prearcing_joule":"5.800","Application":"Fuse link for DC link protection of railway inverter.","UL_certificate":"","price":"1887.8631","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735603-fuse-link-s2m-394-160a-nh2-nh-160a-4000v-ar-15ms"},{"ID":"42806","eti_code":"004735604","descr":"S2M\/394\/200A 4000V DC","seo_name":"Fuse link S2M\/394\/200A NH2 NH 200A 4000V aR 15ms","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"3.6","weight_em":"kg","basic_packaging":null,"shipping_packaging":null,"stock_type":null,"file_link":"\/images\/product_db\/levels\/en-GB\/4285_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735604|Fuse link, S2M\/394\/200A 4000V DC|Special fuses|Fuses for railway applications|Railway fuses|NH2 S\/394\/ DC 4000V aR|NH2 S\/394\/ DC 4000V aR|with centre trip indicator for microswitch MK|Special purpose fuses|Fuses for railway applications|S2M\/394\/200A 400|Rated current 200A|Type NH|Size NH2|Product group Special purpose fuses|Product subgroup railway|Characteristics aR|Rated DC voltage 4000V|Dimensions S394mm|Indicator Centre trip indicator for MK|Breaking capacity DC 30kA|Power dissipation 127W|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards IEC 60269-4 , IEC 60077-5|Operating joule integral 100.000A2s|L\/R 15ms|Prearcing joule integral 10.000A2s|Application Fuse link for DC link protection of railway inverter.|Fuse link S2M\/394\/200A NH2 NH 200A 4000V aR 15ms|","stockammount":"0","stockstatus":"0","rated_current":"200","type":"NH","size":"NH2","charact":"aR","rated_dc_voltage":"4000","dimensions":"S394mm","indicator":"Centre trip indicator for MK","breaking_capacity_dc":"30","pd_w":"127","Standards":"IEC 60269-4 , IEC 60077-5","Power_dissip_07":"","Operating_joule":"100.000","L_R":"15","Prearcing_joule":"10.000","Application":"Fuse link for DC link protection of railway inverter.","UL_certificate":"","price":"2321.1431","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735604-fuse-link-s2m-394-200a-nh2-nh-200a-4000v-ar-15ms"},{"ID":"42807","eti_code":"004735605","descr":"S2M\/394\/250A 4000V DC","seo_name":"Fuse link S2M\/394\/250A NH2 NH 250A 4000V aR 15ms","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"3.6","weight_em":"kg","basic_packaging":null,"shipping_packaging":null,"stock_type":null,"file_link":"\/images\/product_db\/levels\/en-GB\/4285_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735605|Fuse link, S2M\/394\/250A 4000V DC|Special fuses|Fuses for railway applications|Railway fuses|NH2 S\/394\/ DC 4000V aR|NH2 S\/394\/ DC 4000V aR|with centre trip indicator for microswitch MK|Special purpose fuses|Fuses for railway applications|S2M\/394\/250A 400|Rated current 250A|Type NH|Size NH2|Product group Special purpose fuses|Product subgroup railway|Characteristics aR|Rated DC voltage 4000V|Dimensions S394mm|Indicator Centre trip indicator for MK|Breaking capacity DC 30kA|Power dissipation 160W|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards IEC 60269-4 , IEC 60077-5|Operating joule integral 180.000A2s|L\/R 15ms|Prearcing joule integral 21.000A2s|Application Fuse link for DC link protection of railway inverter.|Fuse link S2M\/394\/250A NH2 NH 250A 4000V aR 15ms|","stockammount":"0","stockstatus":"0","rated_current":"250","type":"NH","size":"NH2","charact":"aR","rated_dc_voltage":"4000","dimensions":"S394mm","indicator":"Centre trip indicator for MK","breaking_capacity_dc":"30","pd_w":"160","Standards":"IEC 60269-4 , IEC 60077-5","Power_dissip_07":"","Operating_joule":"180.000","L_R":"15","Prearcing_joule":"21.000","Application":"Fuse link for DC link protection of railway inverter.","UL_certificate":"","price":"2321.1431","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735605-fuse-link-s2m-394-250a-nh2-nh-250a-4000v-ar-15ms"},{"ID":"19806","eti_code":"004735555","descr":"DB1kV TYP:OH15NN1000V\/7,5A","seo_name":"Fuse link DB1kV DB1 DB 7,5A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735555|Fuse link, DB1kV TYP:OH15NN1000V\/7,5A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH15NN|Rated current 7,5A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 7,5A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"7,5","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735555-fuse-link-db1kv-db1-db-7-5a-1000v"},{"ID":"19807","eti_code":"004735556","descr":"DB1kV TYP:OH17NN1000V\/10A","seo_name":"Fuse link DB1kV DB1 DB 10A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735556|Fuse link, DB1kV TYP:OH17NN1000V\/10A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH17NN|Rated current 10A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 10A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"10","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735556-fuse-link-db1kv-db1-db-10a-1000v"},{"ID":"19808","eti_code":"004735557","descr":"DB1kV TYP:OH22NN1000V\/16A","seo_name":"Fuse link DB1kV DB1 DB 16A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735557|Fuse link, DB1kV TYP:OH22NN1000V\/16A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH22NN|Rated current 16A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 16A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"16","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735557-fuse-link-db1kv-db1-db-16a-1000v"},{"ID":"19809","eti_code":"004735558","descr":"DB1kV TYP:OH24NN1000V\/20A","seo_name":"Fuse link DB1kV DB1 DB 20A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735558|Fuse link, DB1kV TYP:OH24NN1000V\/20A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH24NN|Rated current 20A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 20A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"20","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735558-fuse-link-db1kv-db1-db-20a-1000v"},{"ID":"19810","eti_code":"004735559","descr":"DB1kV TYP:OH26NN1000V\/25A","seo_name":"Fuse link DB1kV DB1 DB 25A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735559|Fuse link, DB1kV TYP:OH26NN1000V\/25A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH26NN|Rated current 25A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 25A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"25","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735559-fuse-link-db1kv-db1-db-25a-1000v"},{"ID":"19811","eti_code":"004735560","descr":"DB1kV TYP:OH27NN1000V\/30A","seo_name":"Fuse link DB1kV DB1 DB 30A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735560|Fuse link, DB1kV TYP:OH27NN1000V\/30A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH27NN|Rated current 30A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 30A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"30","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735560-fuse-link-db1kv-db1-db-30a-1000v"},{"ID":"19812","eti_code":"004735561","descr":"DB1kV TYP:OH31NN1000V\/35A","seo_name":"Fuse link DB1kV DB1 DB 35A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735561|Fuse link, DB1kV TYP:OH31NN1000V\/35A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH31NN|Rated current 35A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 35A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"35","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735561-fuse-link-db1kv-db1-db-35a-1000v"},{"ID":"19813","eti_code":"004735562","descr":"DB1kV TYP:OH34NN1000V\/40A","seo_name":"Fuse link DB1kV DB1 DB 40A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735562|Fuse link, DB1kV TYP:OH34NN1000V\/40A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH34NN|Rated current 40A|Type DB|Size DB1|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB1 DB 40A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"40","type":"DB","size":"DB1","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735562-fuse-link-db1kv-db1-db-40a-1000v"},{"ID":"19814","eti_code":"004735564","descr":"DB1kV TYP:OH36NP1000V\/50A","seo_name":"Fuse link DB1kV DB2 DB 50A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"4","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3284_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735564|Fuse link, DB1kV TYP:OH36NP1000V\/50A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB2|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH36NP|Rated current 50A|Type DB|Size DB2|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB2 DB 50A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"50","type":"DB","size":"DB2","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735564-fuse-link-db1kv-db2-db-50a-1000v"},{"ID":"19815","eti_code":"004735566","descr":"DB1kV TYP:OH37PP1000V\/60A","seo_name":"Fuse link DB1kV DB3 DB 60A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3286_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735566|Fuse link, DB1kV TYP:OH37PP1000V\/60A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB3|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH37PP|Rated current 60A|Type DB|Size DB3|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB3 DB 60A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"60","type":"DB","size":"DB3","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"48.8201","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735566-fuse-link-db1kv-db3-db-60a-1000v"},{"ID":"19856","eti_code":"004735567","descr":"DB1,5kVTYP:OK15PP1500V7,5A","seo_name":"Fuse link DB1,5kVTYP:OK15PP1500V7,5A DB3 DB 7,5A 1500V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735567|Fuse link, DB1,5kVTYP:OK15PP1500V7,5A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1500V|Special purpose fuses|Fuses for railway applications|DB1,5KVTYP:OK15P|Rated current 7,5A|Type DB|Size DB3|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1500V|Rated DC voltage 1500V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1,5kVTYP:OK15PP1500V7,5A DB3 DB 7,5A 1500V|","stockammount":"0","stockstatus":"0","rated_current":"7,5","type":"DB","size":"DB3","charact":"","rated_dc_voltage":"1500","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"60.2585","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735567-fuse-link-db1-5kvtyp-ok15pp1500v7-5a-db3-db-7-5a-1500v"},{"ID":"19857","eti_code":"004735568","descr":"DB1,5kVTYP:OK24PP1500V\/20A","seo_name":"Fuse link DB1,5kVTYP:OK24PP1500V\/20A DB3 DB 20A 1500V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735568|Fuse link, DB1,5kVTYP:OK24PP1500V\/20A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1500V|Special purpose fuses|Fuses for railway applications|DB1,5KVTYP:OK24P|Rated current 20A|Type DB|Size DB3|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1500V|Rated DC voltage 1500V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1,5kVTYP:OK24PP1500V\/20A DB3 DB 20A 1500V|","stockammount":"0","stockstatus":"0","rated_current":"20","type":"DB","size":"DB3","charact":"","rated_dc_voltage":"1500","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"60.2585","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735568-fuse-link-db1-5kvtyp-ok24pp1500v-20a-db3-db-20a-1500v"},{"ID":"19858","eti_code":"004735571","descr":"DB1kV TYP:OH39PQ1000V\/70A","seo_name":"Fuse link DB1kV DB4 DB 70A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"4.4","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3289_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735571|Fuse link, DB1kV TYP:OH39PQ1000V\/70A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB4|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH39PQ|Rated current 70A|Type DB|Size DB4|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB4 DB 70A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"70","type":"DB","size":"DB4","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"77.6328","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735571-fuse-link-db1kv-db4-db-70a-1000v"},{"ID":"19859","eti_code":"004735573","descr":"DB TYP:OK 34LP 1500V\/40A","seo_name":"Fuse link DB DB5 DB 40A 1500V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"0","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3291_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735573|Fuse link, DB TYP:OK 34LP 1500V\/40A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB5|1500V|Special purpose fuses|Fuses for railway applications|DB TYP:OK 34LP 1|Rated current 40A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1500V|Rated DC voltage 1500V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB DB5 DB 40A 1500V|","stockammount":"0","stockstatus":"0","rated_current":"40","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"1500","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"64.1982","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735573-fuse-link-db-db5-db-40a-1500v"},{"ID":"19860","eti_code":"004735575","descr":"DB1,5kVTYP:OK37LP1500V\/60A","seo_name":"Fuse link DB1,5kVTYP:OK37LP1500V\/60A DB5 DB 60A 1500V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/2876_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735575|Fuse link, DB1,5kVTYP:OK37LP1500V\/60A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB1|1500V|Special purpose fuses|Fuses for railway applications|DB1,5KVTYP:OK37L|Rated current 60A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1500V|Rated DC voltage 1500V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1,5kVTYP:OK37LP1500V\/60A DB5 DB 60A 1500V|","stockammount":"0","stockstatus":"0","rated_current":"60","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"1500","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"64.1982","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735575-fuse-link-db1-5kvtyp-ok37lp1500v-60a-db5-db-60a-1500v"},{"ID":"19861","eti_code":"004735576","descr":"DB3kV TYP:ON17RP3000V\/10A","seo_name":"Fuse link DB3kV DB5 DB 10A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735576|Fuse link, DB3kV TYP:ON17RP3000V\/10A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON17RP|Rated current 10A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB5 DB 10A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"10","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"96.5935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735576-fuse-link-db3kv-db5-db-10a-3000v"},{"ID":"19862","eti_code":"004735577","descr":"DB3kV TYP:ON21RP3000V\/15A","seo_name":"Fuse link DB3kV DB5 DB 15A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3291_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735577|Fuse link, DB3kV TYP:ON21RP3000V\/15A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB5|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON21RP|Rated current 15A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB5 DB 15A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"15","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"96.5935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735577-fuse-link-db3kv-db5-db-15a-3000v"},{"ID":"19863","eti_code":"004735578","descr":"DB3kV TYP:ON24RP3000V\/20A","seo_name":"Fuse link DB3kV DB5 DB 20A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735578|Fuse link, DB3kV TYP:ON24RP3000V\/20A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON24RP|Rated current 20A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB5 DB 20A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"20","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"96.5935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735578-fuse-link-db3kv-db5-db-20a-3000v"},{"ID":"19864","eti_code":"004735580","descr":"DB3kV TYP:ON27RP3000V\/30A","seo_name":"Fuse link DB3kV DB5 DB 30A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735580|Fuse link, DB3kV TYP:ON27RP3000V\/30A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON27RP|Rated current 30A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB5 DB 30A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"30","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"96.5935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735580-fuse-link-db3kv-db5-db-30a-3000v"},{"ID":"19865","eti_code":"004735581","descr":"DB3kV TYP:ON36RP3000V\/50A","seo_name":"Fuse link DB3kV DB5 DB 50A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"1.15","weight_em":"kg","basic_packaging":"2","shipping_packaging":"12","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735581|Fuse link, DB3kV TYP:ON36RP3000V\/50A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON36RP|Rated current 50A|Type DB|Size DB5|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB5 DB 50A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"50","type":"DB","size":"DB5","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"96.5935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"2","alias":"004735581-fuse-link-db3kv-db5-db-50a-3000v"},{"ID":"19866","eti_code":"004735583","descr":"DB1kV TYP:OH43TQ1000V\/100A","seo_name":"Fuse link DB1kV DB6 DB 100A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"4.4","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735583|Fuse link, DB1kV TYP:OH43TQ1000V\/100A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH43TQ|Rated current 100A|Type DB|Size DB6|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB6 DB 100A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"100","type":"DB","size":"DB6","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"142.4935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735583-fuse-link-db1kv-db6-db-100a-1000v"},{"ID":"19867","eti_code":"004735584","descr":"DB1kV TYP:OH45TQ1000V\/125A","seo_name":"Fuse link DB1kV DB6 DB 125A 1000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"4.4","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735584|Fuse link, DB1kV TYP:OH45TQ1000V\/125A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|1000V|Special purpose fuses|Fuses for railway applications|DB1KV TYP:OH45TQ|Rated current 125A|Type DB|Size DB6|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 1000V|Rated DC voltage 1000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB1kV DB6 DB 125A 1000V|","stockammount":"0","stockstatus":"0","rated_current":"125","type":"DB","size":"DB6","charact":"","rated_dc_voltage":"1000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"142.4935","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735584-fuse-link-db1kv-db6-db-125a-1000v"},{"ID":"19868","eti_code":"004735585","descr":"DB3kV TYP:ON17TQ3000V\/10A","seo_name":"Fuse link DB3kV DB6 DB 10A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"4.4","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735585|Fuse link, DB3kV TYP:ON17TQ3000V\/10A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON17TQ|Rated current 10A|Type DB|Size DB6|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB6 DB 10A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"10","type":"DB","size":"DB6","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"120.7369","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735585-fuse-link-db3kv-db6-db-10a-3000v"},{"ID":"19869","eti_code":"004735586","descr":"DB3kV TYP:ON24TQ3000V\/20A","seo_name":"Fuse link DB3kV DB6 DB 20A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"4.4","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735586|Fuse link, DB3kV TYP:ON24TQ3000V\/20A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON24TQ|Rated current 20A|Type DB|Size DB6|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB6 DB 20A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"20","type":"DB","size":"DB6","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"120.7369","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735586-fuse-link-db3kv-db6-db-20a-3000v"},{"ID":"19870","eti_code":"004735587","descr":"DB3kV TYP:ON27TQ3000V\/30A","seo_name":"Fuse link DB3kV DB6 DB 30A 3000V","seo_alias":null,"class_name":"Fuse link","id_level":"462","weight":"4.4","weight_em":"kg","basic_packaging":"1","shipping_packaging":"2","stock_type":"pcs","file_link":"\/images\/product_db\/levels\/en-GB\/3294_photo.jpg","tree_depth":"2","tree_title":"Fuses for railway applications","program_type":"1","searchstring":"|004735587|Fuse link, DB3kV TYP:ON27TQ3000V\/30A|Special fuses|Fuses for railway applications|Fuses for high-voltage switchgear|DB|DB6|3000V|Special purpose fuses|Fuses for railway applications|DB3KV TYP:ON27TQ|Rated current 30A|Type DB|Size DB6|Product group Special purpose fuses|Product subgroup railway|Rated AC voltage 3000V|Rated DC voltage 3000V|Catalogue Group Special purpose fuses|Catalogue subgroup Railway Fuse|Standards UIC 550, EN 50163, IEC 60077-5|Application Railway protection|Fuse link DB3kV DB6 DB 30A 3000V|","stockammount":"0","stockstatus":"0","rated_current":"30","type":"DB","size":"DB6","charact":"","rated_dc_voltage":"3000","dimensions":"","indicator":"","breaking_capacity_dc":"","pd_w":"","Standards":"UIC 550, EN 50163, IEC 60077-5","Power_dissip_07":"","Operating_joule":"","L_R":"","Prearcing_joule":"","Application":"Railway protection","UL_certificate":"","price":"120.7369","price_web":null,"price_action":null,"price_discount_web":null,"price_discount_action":null,"vat":null,"stock":"0.00","stock_status":"3","packaging_basic":"1","alias":"004735587-fuse-link-db3kv-db6-db-30a-3000v"}],"columns":[{"name":"eti_code","title":"ETI Code","primary":true},{"name":"descr","title":"Description","primary":false},{"name":"class_name","title":"Class name","primary":false},{"name":"size","title":"Size","primary":false},{"name":"Price","title":"COM_ETIB2B_ORDERS_TABLE_COLUMN_PRICE","cssClass":"price align-right","primary":false},{"name":"StockStatus","title":"COM_ETIB2B_ORDERS_TABLE_COLUMN_AVAILABILITY","primary":false},{"name":"Commands","title":"","primary":false}],"recordsCount":30,"recordsTotalCount":83,"params":{"filters":{"lang":"en-GB","levelId":462,"status":null,"search":null,"programType":0},"pageNumber":1,"pageSize":30,"pageMax":3,"dataEx":{"filterItems":{"size":{"field":"size","values":[{"count":"3","value":"3L"},{"count":"8","value":"DB1"},{"count":"1","value":"DB2"},{"count":"3","value":"DB3"},{"count":"1","value":"DB4"},{"count":"7","value":"DB5"},{"count":"9","value":"DB6"},{"count":"1","value":"DB7"},{"count":"33","value":"NH1"},{"count":"10","value":"NH2"},{"count":"7","value":"S368"}],"trans":"Size"},"type":{"field":"type","values":[{"count":"30","value":"DB"},{"count":"46","value":"NH"},{"count":"7","value":"SZDB"}],"trans":"Type"},"rated_current":{"field":"rated_current","values":[{"count":"2","value":"7,5"},{"count":"3","value":"10"},{"count":"1","value":"15"},{"count":"1","value":"16"},{"count":"5","value":"20"},{"count":"4","value":"25"},{"count":"4","value":"30"},{"count":"3","value":"32"},{"count":"1","value":"35"},{"count":"7","value":"40"},{"count":"7","value":"50"},{"count":"4","value":"60"},{"count":"3","value":"63"},{"count":"3","value":"70"},{"count":"3","value":"80"},{"count":"8","value":"100"},{"count":"6","value":"125"},{"count":"3","value":"150"},{"count":"4","value":"160"},{"count":"4","value":"200"},{"count":"4","value":"250"},{"count":"1","value":"800"},{"count":"1","value":"1000"},{"count":"1","value":"1250"}],"trans":"Rated current (A)"},"rated_dc_voltage":{"field":"rated_dc_voltage","values":[{"count":"22","value":"1000"},{"count":"4","value":"1500"},{"count":"13","value":"3000"},{"count":"37","value":"4000"},{"count":"7","value":"5000"}],"trans":"Rated DC voltage (V)"},"charact":{"field":"charact","values":[{"count":"40","value":"aR"},{"count":"6","value":"gR"}],"trans":"Characteristics"}},"columnsThumbs":[{"column":"class_name","title":"Class name"},{"column":"size","title":"Size"},{"column":"type","title":"Type"},{"column":"rated_current","title":"Rated current (A)"},{"column":"rated_dc_voltage","title":"Rated DC voltage (V)"}],"columnsThumbsAll":[{"column":"class_name","title":"Class name"},{"column":"size","title":"Size"},{"column":"type","title":"Type"},{"column":"rated_current","title":"Rated current (A)"},{"column":"rated_dc_voltage","title":"Rated DC voltage (V)"},{"column":"charact","title":"Characteristics"},{"column":"L_R","title":"L\/R (ms)"},{"column":"breaking_capacity_dc","title":"Breaking capacity DC (kA)"},{"column":"Application","title":"Application"},{"column":"dimensions","title":"Dimensions"}],"programTypes":{"1":{"program_type":"1","Count":"83"}}}}}
