Fuse link NH01XL gBat 160A/1500V DC 004110703
Specifications
- ETI Code:
- 004110703
- Description:
- NH01XL gBat 160A/1500V DC
- Class name:
- Fuse link
- efuse:
- 1
- Rated current (A):
- 160A
- Type:
- NH
- Size:
- NH01XL
- Characteristics:
- gBat
- Rated DC voltage (V):
- 1500V
- Indicator:
- Top fuse status indicator
- Breaking capacity DC (kA):
- 100kA
- Operating joule integral (A2s):
- 104000
- L/R (ms):
- 3ms
- Prearcing joule integral (A2s):
- 13000
- Application:
- Battery protection
- Power dissipation (W):
- 46W
- Power dissipation (0,7x In) (W):
- 17W
- Standards:
- IEC 60269-7
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895855583
- Net weight of the product
- 450 g
- Customs tariff
- 85351000
- logis_net_width
- 29 mm
- logis_net_height
- 194 mm
- logis_net_depth
- 65 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895855590
- Basic packaging weight
- 1.29 kg
Transport packaging
- Transport packaging quantity
- 30
- EAN code for a transport packaging
- 3838400144003
- Transport packaging weight
- 14.25 kg
- Pallet quantity
- 1560
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 160
- Rated voltage
- 1500
- Voltage type
- DC
- Rated switching capacity
- 100
- Utilization category
- Other
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
NH01XL gBat 160A/1500V DC
