Fuse link NH2/K gBat 250A/550V DC 004724284
Specifications
- ETI Code:
- 004724284
- Description:
- NH2/K gBat 250A/550V DC
- Class name:
- Fuse link
- Rated current (A):
- 250
- Type:
- NH-K
- Size:
- NH2
- Characteristics:
- gBat
- Rated DC voltage (V):
- 550
- Indicator:
- Striker pin status indicator
- Breaking capacity DC (kA):
- 30
- Operating joule integral (A2s):
- 70.200
- L/R (ms):
- 3
- Prearcing joule integral (A2s):
- 15.000
- Application:
- Battery protection
- Power dissipation (W):
- 43
- Power dissipation (0,7x In) (W):
- 19,3
- Standards:
- IEC 60269-7
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895758976
- Net weight of the product
- 0.66 kg
- Customs tariff
- 85361090
- logis_net_width
- 55 mm
- logis_net_height
- 151 mm
- logis_net_depth
- 72 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895689454
- Basic packaging weight
- 2.05 kg
Transport packaging
- Transport packaging quantity
- 24
- EAN code for a transport packaging
- 3838895689461
- Transport packaging weight
- 17.95 kg
- Pallet quantity
- 576
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH2
- Rated current
- 250
- Rated voltage
- 550
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- Other
- Type of fuse status indicator
- Other
- Insulated metal gripping lugs (IMGL)
- No
