Fuse link NHU1/110 aR 160A/1000V DC 004110844
Specifications
- ETI Code:
- 004110844
- Description:
- NHU1/110 aR 160A/1000V DC
- Class name:
- Fuse link
- Application:
- For protection on DC side of EV chargers
- Standards:
- IEC 60269-4
- Prearcing joule integral (A2s):
- 2.000
- Power dissipation (0,7xIn) (W):
- 14,9
- Power dissipation (W):
- 41,8
- Operating joule integral (A2s):
- 31.000
- L/R (ms):
- 2
- Breaking capacity DC (kA):
- 30
- Indicator:
- Top fuse status indicator
- Type:
- NH-U
- Size:
- 1/110
- Rated current (A):
- 160
- Rated DC voltage (V):
- 1000
- Characteristics:
- aR
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 500 g
- Customs tariff
- 85361090
Level 1 Packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838400102379
- Basic packaging weight
- 0.6 kg
Level 2 Packaging
- Transport packaging quantity
- 26
- EAN code for a transport packaging
- 3838400102386
- Transport packaging weight
- 15.95 kg
- Pallet quantity
- 1352
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 160
- Rated voltage
- 1000
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Top fuse status indicator
NHU1/110 aR 160A/1000V DC
