Aux.contactor CECA0.13-220V-DC 004641172
Specifications
- ETI Code:
- 004641172
- Description:
- CECA0.13-220V-DC
- Class name:
- Aux.contactor
- Rated operation current Ie at AC1 (A):
- 10
- Rated operational voltage AC (V):
- 230
- Rated DC control circuit voltage Uc (V):
- 220V
- Number of auxiliary NO contacts:
- 1
- Number of auxiliary NC contacts:
- 3
- Function:
- Auxiliary contactors
Documents
Logistic Data
Product
- Customs tariff
- 85364900
- logis_net_width
- 46 mm
- logis_net_height
- 58 mm
- logis_net_depth
- 52 mm
Transport packaging
- Transport packaging quantity
- 1
- EAN code for a transport packaging
- 7890355552773
- Transport packaging weight
- 0.229 kg
- Pallet quantity
- 3478
ETIM Clasification
- Classification
- EC000196
- Class name
- Contactor relay
- Rated control supply voltage DC
- 220…220V
- Voltage type for actuating
- DC
- Rated operation current Ie, 400 V
- 10A
- Connection type auxiliary circuit
- Screw connection
- Number of auxiliary contacts as normally closed contact
- 3
- Number of auxiliary contacts as normally open contact
- 1
