RCCB EFI-P4R B G/KV 100/0.1 002061915
Specifications
- ETI Code:
- 002061915
- Description:
- EFI-P4R B G/KV 100/0.1
- Class name:
- RCCB
- Rated residual current (A):
- 0.1
- Current type:
- AC
- Rated current (A):
- 100
- Type:
- B
- Number of poles:
- 4
- Rated conditional short-circuit current Inc (kA):
- 10
- Tripping time:
- G/KV (Short time delay)
- Rated voltage (V):
- 400
- Rated Frequency (Hz):
- 50/60
- Rated cross section:
- 1-50
- Standards:
- IEC/EN 61008-1
- IP rating:
- IP20
- Mounting type:
- TH 35
- Depth (mm):
- 71
Documents
Logistic Data
Product
- Customs tariff
- 85362090
- logis_net_width
- 70 mm
- logis_net_height
- 85 mm
- logis_net_depth
- 69 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895928904
- Basic packaging weight
- 0.38 kg
Transport packaging
- Transport packaging quantity
- 27
- EAN code for a transport packaging
- 3838895928911
- Transport packaging weight
- 10.56 kg
- Pallet quantity
- 1404
ETIM Clasification
- Classification
- EC000003
- Class name
- Residual current circuit breaker (RCCB)
- Number of poles
- 4
- Rated voltage
- 400V
- Rated current
- 100A
- Rated fault current
- 100mA
- Rated insulation voltage Ui
- 500V
- Rated impulse withstand voltage Uimp
- 4kV
- Mounting method
- DIN rail
- Leakage current type
- AC
- Selective protection
- No
- Short-time delayed tripping
- Yes
- Short-circuit breaking capacity (Icw)
- 10kA
- Surge current capacity
- 3kA
- Frequency
- 50/60 Hz
- Additional equipment possible
- Yes
- With interlocking device
- No
- Degree of protection (IP)
- IP20
- Width in number of modular spacings
- 4
- Built-in depth
- 71mm
- Ambient temperature during operating
- -25…40°C
- Pollution degree
- 2
- Connectable conductor cross section multi-wired
- 1…50mm²
- Connectable conductor cross section solid-core
- 1…50mm²
