Fuse link NHS3/80/M UQ01 aR 1000A/690V 004385732
Specifications
- ETI Code:
- 004385732
- Description:
- NHS3/80/M UQ01 aR 1000A/690V
- Class name:
- Fuse link
- Product group:
- Semiconductor Protection
- Type:
- NH-S
- Size:
- NH3
- Rated current (A):
- 1000A
- Rated AC voltage (V):
- 690V
- Rated DC voltage (V):
- 690V
- Characteristics:
- aR
- Breaking capacity AC (kA):
- 200kA
- Application:
- For protection of semiconductor devices
- Indicator:
- Centre trip indicator for MK
- Power dissipation (W):
- 131W
- Operating joule integral (A2s):
- 1000000
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- Net weight of the product
- 950 g
- Customs tariff
- 85361090
- logis_net_width
- 79 mm
- logis_net_height
- 109 mm
- logis_net_depth
- 73 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895347231
- Basic packaging weight
- 0.972 kg
Transport packaging
- Transport packaging quantity
- 12
- EAN code for a transport packaging
- 3838895558613
- Transport packaging weight
- 11.68 kg
- Pallet quantity
- 1344
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH3
- Rated current
- 1000
- Rated voltage
- 690
- Voltage type
- AC
- Rated switching capacity
- 200
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Centre fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
