Fuse link VVC3 12kV/125A 004230018
Specifications
- ETI Code:
- 004230018
- Description:
- VVC3 12kV/125A
- Class name:
- Fuse link
- efuse:
- 1
- Rated minimum breaking current (A):
- 450A
- Cold resistance (mΩ):
- 52mΩ
- Rated current (A):
- 125A
- Type:
- NEW VVC 50N striker
- Size:
- 292
- Rated AC voltage (V):
- 12000V
- Indicator:
- 50N striker force
- Breaking capacity AC (kA):
- 63kA
- Power dissipation (W):
- 138W
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895915744
- Net weight of the product
- 3.8 kg
- Customs tariff
- 85351000
- logis_net_width
- 87 mm
- logis_net_height
- 358 mm
- logis_net_depth
- 87 mm
Transport packaging
- Transport packaging quantity
- 3
- EAN code for a transport packaging
- 3838895915751
- Transport packaging weight
- 12.02 kg
- Pallet quantity
- 90
ETIM Clasification
- Classification
- EC003507
- Class name
- Medium-/high voltage fuse
- Rated current
- 125A
- Rated voltage
- 12kV
- Voltage type
- AC
- Rated frequency
- 45…60Hz
- Breaking capacity
- 63kA
- Utilization category
- Other
- Application
- Other
- Length
- 292mm
- Diameter
- 83,5mm
- Performance category according to IEC 60282-1
- Back-up
- With striker
- Yes
- Standard
- IEC
- Installation technique
- Air
