Fuse link NHS3L gPV 350A/1500V DC 004110603 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 004110603
- Description:
- *NHS3L gPV 350A/1500V DC
- Class name:
- Fuse link
- Type:
- NH
- Size:
- 3L
- Rated current (A):
- 350
- Rated DC voltage (V):
- 1500
- Characteristics:
- gPV
- L/R (ms):
- 3
- Breaking capacity DC (kA):
- 30
- Application:
- Fuse-link for DC application
- Dimensions:
- S170mm
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 63
- Power dissipation (0,7x In) (W):
- 25,5
- Operating joule integral (A2s):
- 200.000
- Prearcing joule integral (A2s):
- 140.000
- Standards:
- IEC 60269-6, UL 248-19
- UL certificate:
- E347771
Documents
Logistic Data
Product
- Customs tariff
- 85351000
- logis_net_width
- 73 mm
- logis_net_height
- 198 mm
- logis_net_depth
- 73 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895737490
- Basic packaging weight
- 1.36 kg
Transport packaging
- Transport packaging quantity
- 9
- EAN code for a transport packaging
- 3838895737506
- Transport packaging weight
- 12.475 kg
- Pallet quantity
- 468
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 350
- Rated voltage
- 1500
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- gPV (photovoltaic protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
*NHS3L gPV 350A/1500V DC
