Fuse link CH10x38 gG 12A/500V 002620008 Obsolete

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

Specifications

ETI Code:
002620008
Description:
*CH10x38 gG 12A/500V
Class name:
Fuse link
efuse:
1
Type:
CH
Size:
CH10
Rated current (A):
12
Rated AC voltage (V):
500
Characteristics:
gG
Breaking capacity AC (kA):
100
Application:
For cable protection
Dimensions:
10X38
Power dissipation (W):
1,6
Standards:
IEC 60269-1, IEC 60269-2

Documents

Product

EAN code for a single product
3838895581567
Net weight of the product
7.6  g
Customs tariff
85361050
logis_net_width
10  mm
logis_net_height
38  mm
logis_net_depth
10  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895137702
Basic packaging weight
0.08  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895164999
Transport packaging weight
4.1  kg
Pallet quantity
84000
Classification
EC002704
Class name
Cylindrical fuse
Size
10x38 mm
Utilization category
Other
Nominal current
12A
Breaking capacity
100kA
ETIM Classification – Version 7.0
