Fuse link CH10x85SU gR 20A/1200V DC 002625237

Specifications

ETI Code:
002625237
Description:
CH10x85SU gR 20A/1200V DC
Class name:
Fuse link
efuse:
1
Product group:
Special purpose fuses
Product subgroup:
PV
L/R (ms):
2
Designed for:
Protection of PV installations
Type:
CH SU
Size:
CH10
Rated current (A):
20
Rated DC voltage (V):
1200
Characteristics:
gR
Breaking capacity DC (kA):
30
Application:
For protection of semiconductor devices
Dimensions:
10x85
Power dissipation (0,7xIn) (W):
1,68
Power dissipation (W):
3,85
Prearcing joule integral (A2s):
212
Operating joule integral (A2s):
314
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838400052759
Net weight of the product
18.1  g
Customs tariff
85351000
logis_net_width
10  mm
logis_net_height
107  mm
logis_net_depth
11  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895611974
Basic packaging weight
0.195  kg

Level 2 Packaging

Transport packaging quantity
160
EAN code for a transport packaging
3838895611981
Transport packaging weight
3.2  kg
Pallet quantity
27200
Classification
EC002704
Class name
Cylindrical fuse
Construction size
CH10
Rated voltage DC
1200
Application
For protection of semiconductor devices
Rated current
20
Size
Other
Rated voltage
Other
Utilization category
Other
Nominal current
20A
ETIM Classification – Version 7.0
