Fuse link CH14x51 aR 16A/690V 002635009

Specifications

ETI Code:
002635009
Description:
CH14x51 aR 16A/690V
Class name:
Fuse link
Type:
CH
Size:
CH14
Rated current (A):
16
Rated AC voltage (V):
690
Characteristics:
aR
Breaking capacity AC (kA):
200
Breaking capacity DC (kA):
50
Application:
For protection of semiconductor devices
Dimensions:
14x51
Power dissipation (W):
5,5
Operating joule integral (A2s):
75
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
Net weight of the product
0.039 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895356257
Basic packaging weight
0.22 kg
Basic packaging volume
0.12

Transport packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895356257
Transport packaging weight
0.22 kg
Transport packaging volume
0.12
Pallet quantity
30000
Pallet volume
360
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
200kA
Nominal current
16A
Size
14x51 mm
Utilization category
Other
ETIM Classification – Version 7.0
