Fuse link CH14x51 aR 25A/690V 002635013

Specifications

ETI Code:
002635013
Description:
CH14x51 aR 25A/690V
Class name:
Fuse link
Type:
CH
Size:
CH14
Rated current (A):
25
Rated AC voltage (V):
690
Characteristics:
aR
Breaking capacity AC (kA):
200
Breaking capacity DC (kA):
50
Application:
For protection of semiconductor devices
Dimensions:
14x51
Power dissipation (W):
7
Operating joule integral (A2s):
320
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
Net weight of the product
0.039 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895356271
Basic packaging weight
0.22 kg
Basic packaging volume
0.12

Transport packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895356271
Transport packaging weight
0.22 kg
Transport packaging volume
0.12
Pallet quantity
30000
Pallet volume
360
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
200kA
Nominal current
25A
Size
14x51 mm
Utilization category
Other
ETIM Classification – Version 7.0

Images & Diagrams

002635013Fuse link, CH14x51 aR 25A/690VUltra QuickSystem CaR CharacteristicaR CharacteristicCH14CH14Fuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKCH14X51 AR 25A/6Rated current 25AType CHSize CH14Product group Semiconductor ProtectionCharacteristics aRRated AC voltage 690VDimensions 14x51Breaking capacity AC 200kABreaking capacity DC 50kAPower dissipation 7WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 320A2sApplication For protection of semiconductor devicesFuse link CH14x51 CH CH14 25A 690V aR
