Fuse link CH22x85 aR 80A/600V 002645023

Specifications

ETI Code:
002645023
Description:
CH22x85 aR 80A/600V
Class name:
Fuse link
Type:
CH
Size:
CH22
Rated current (A):
80
Rated AC voltage (V):
600
Characteristics:
aR
Breaking capacity AC (kA):
200
Breaking capacity DC (kA):
50
Application:
For protection of semiconductor devices
Dimensions:
22x58
Power dissipation (W):
13,5
Operating joule integral (A2s):
6.600
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
Net weight of the product
0.061 kg
Customs tariff
85361090

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895356455
Basic packaging weight
0.44 kg
Basic packaging volume
0.3

Transport packaging

Transport packaging quantity
10
EAN code for a transport packaging
3838895356455
Transport packaging weight
0.44 kg
Transport packaging volume
0.3
Pallet quantity
15000
Pallet volume
450
Classification
EC002704
Class name
Cylindrical fuse
Breaking capacity
200kA
Nominal current
80A
Size
22x58 mm
Utilization category
Other
ETIM Classification – Version 7.0
