Fuse link NH2XL gPV 250A/1100V DC 004110413
Specifications
- ETI Code:
- 004110413
- Description:
- NH2XL gPV 250A/1100V DC
- Class name:
- Fuse link
- efuse:
- 1
- Type:
- NH
- Size:
- 2XL
- Rated current (A):
- 250
- Rated DC voltage (V):
- 1100
- Characteristics:
- gPV
- L/R (ms):
- 5
- Breaking capacity DC (kA):
- 10
- Application:
- Fuse-link for DC application
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 46
- Power dissipation (0,7xIn) (W):
- 17,9
- Operating joule integral (A2s):
- 117.400
- Prearcing joule integral (A2s):
- 85.260
- Standards:
- IEC 60269-6
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 1050 g
- Customs tariff
- 85351000
- logis_net_width
- 55 mm
- logis_net_height
- 209 mm
- logis_net_depth
- 71 mm
Level 1 Packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895503804
- Basic packaging weight
- 1.06 kg
Level 2 Packaging
- Transport packaging quantity
- 15
- EAN code for a transport packaging
- 3838895534440
- Transport packaging weight
- 15.91 kg
- Pallet quantity
- 780
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 250
- Rated voltage
- 1100
- Voltage type
- DC
- Rated switching capacity
- 10
- Utilization category
- gPV (photovoltaic protection)
- Type of fuse status indicator
- Top fuse status indicator
