Fuse link NHU00/90 gBat 50A/1000V DC 004110952
Specifications
- ETI Code:
- 004110952
- Description:
- NHU00/90 gBat 50A/1000V DC
- Class name:
- Fuse link
- efuse:
- 1
- Rated current (A):
- 50
- Type:
- NH-U
- Size:
- NH00
- Characteristics:
- gBat
- Rated DC voltage (V):
- 1000
- Indicator:
- Top fuse status indicator
- Breaking capacity DC (kA):
- 30
- Operating joule integral (A2s):
- 920
- L/R (ms):
- 1
- Prearcing joule integral (A2s):
- 155
- Application:
- Battery protection
- Power dissipation (W):
- 14,1
- Power dissipation (0,7x In) (W):
- 5,7
- Standards:
- IEC 60269-7
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400122896
- Net weight of the product
- 0.3 kg
- Customs tariff
- 85361050
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838400122902
- Basic packaging weight
- 0.95 kg
Transport packaging
- Transport packaging quantity
- 45
- EAN code for a transport packaging
- 3838400122926
- Transport packaging weight
- 14.6 kg
- Pallet quantity
- 2340
NHU00/90 gBat 50A/1000V DC
