Fuse link S1UQ01/110/315A/1000V 004303121
Specifications
- ETI Code:
- 004303121
- Description:
- S1UQ01/110/315A/1000V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- NH
- Size:
- NH1
- Rated current (A):
- 315
- Rated AC voltage (V):
- 1000
- Characteristics:
- aR
- Breaking capacity AC (kA):
- 200
- Application:
- For protection of semiconductor devices
- Dimensions:
- S110mm
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 60
- Operating joule integral (A2s):
- 110.000
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- Net weight of the product
- 0.64 kg
- Customs tariff
- 85361090
- logis_net_width
- 51 mm
- logis_net_height
- 140 mm
- logis_net_depth
- 51 mm
Level 1 Packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895348368
- Basic packaging weight
- 0.6 kg
Level 2 Packaging
- Transport packaging quantity
- 26
- EAN code for a transport packaging
- 3838895559894
- Transport packaging weight
- 15.95 kg
- Pallet quantity
- 1352
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH1
- Rated current
- 315
- Rated voltage
- 1000
- Voltage type
- AC
- Rated switching capacity
- 200
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Top fuse status indicator
