Miniature circuit breaker ETIMAT RC 3p B16 631630102 Obsolete
This product is obsolete and has been replaced with 001907310.
Compare products
Specifications
- ETI Code:
- 631630102
- Description:
- *ETIMAT RC 3p B16
- Class name:
- Miniature circuit breaker
- Rated current (A):
- 16
- Tripping characteristic:
- B
- Number of poles:
- 3
- Short circuit capacity (kA):
- 10
- Voltage type:
- AC
- Rated voltage (V):
- 400
- Rated Frequency (Hz):
- 50
- Rated impulse withstand voltage Uimp (kV):
- 4
- Rated cross section:
- 1-25
- Standards:
- EN 60669-2-2
- Function:
- MCB
Documents
Logistic Data
Product
- Customs tariff
- 85362010
- logis_net_width
- 72 mm
- logis_net_height
- 90 mm
- logis_net_depth
- 75 mm
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895589891
- Basic packaging weight
- 0.503 kg
Transport packaging
- Transport packaging quantity
- 10
- EAN code for a transport packaging
- 3838895589907
- Transport packaging weight
- 5.22 kg
- Pallet quantity
- 10
*ETIMAT RC 3p B16
