Molded Case Circuit Breaker EB2 400/4HLCD 400A 4p APGNSCWH 004672298
Specifications
- ETI Code:
- 004672298
- Description:
- EB2 400/4HLCD 400A 4p APGNSCWH
- Class name:
- Molded Case Circuit Breaker
- Catalogue Group:
- EB2
- Rated current (A):
- 400A
- Number of poles:
- 4
- Connection type:
- front connection
- Rated impulse withstand voltage Uimp (kV):
- 8kV
- Rated short-circuit breaking capacity at 415V Icu/Ics (kA):
- 70kA
- Rated operational voltage AC (V):
- 690V
- Rated insulation voltage (V):
- 800V
- Thermal adjustment:
- 0,4-1
- Magnetic adjustment:
- adjustable
- Adjustable or fixed:
- adjustable
- Standards:
- 60947
Documents
Logistic Data
Product
- Net weight of the product
- 5.7 kg
- Customs tariff
- 85362090
- logis_net_width
- 185 mm
- logis_net_height
- 260 mm
- logis_net_depth
- 145 mm
Transport packaging
- Transport packaging quantity
- 1
- EAN code for a transport packaging
- 3838895703877
- Transport packaging weight
- 5.7 kg
- Pallet quantity
- 140
Images & Diagrams
