Fuse disconnector VLC 14 DC 2p LED 002563102 Obsolete
This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.
Specifications
- ETI Code:
- 002563102
- Description:
- *VLC 14 DC 2p LED
- Class name:
- Fuse disconnector
- Rated current (A):
- 50
- Number of poles:
- 2
- Rated DC voltage (V):
- 1000
- Indicator:
- LED
- Product group:
- LV-fuse disconnector
- Connection:
- 35mm2
- Catalogue Group:
- LV-fuse disconnector
Documents
Logistic Data
Product
- Customs tariff
- 85389099
Basic packaging
- Basic packaging quantity
- 6
- EAN code for a basic packaging
- 3838895596516
- Basic packaging weight
- 1.209 kg
Transport packaging
- Transport packaging quantity
- 48
- EAN code for a transport packaging
- 3838895596523
- Transport packaging weight
- 10.3 kg
- Pallet quantity
- 1152
ETIM Clasification
- Classification
- EC001040
- Class name
- Fuse switch disconnector
- Rated permanent current Iu
- 50A
- Suitable for fuses
- Other
- Number of poles
- 2
- With error protection
- Yes
- Type of electrical connection of main circuit
- Frame clamp
- Suitable for busbar mounting
- Yes
- Type of control element
- Cover grip
- Degree of protection (IP), front side
- IP20
*VLC 14 DC 2p LED
